1940 North American NA-64 Yale
1940 · CF-JTN ·
Platinum Fighter Sales
Specifications
Airframe
- Total time
- 2,035 hr
- MSN
- 121217
Performance (across variants)
- Range
- 800 nm
- Service ceiling
- 16,500 ft
- MTOW
- 2,100 kg
- Passengers
- Up to 2
Description
Engine: Installed overhauled Wright R-975-28 SN:40426. Cowling was dis-assembled cleaned and NDT inspected. Parts replaced as necessary with NOS and new made IAW NAA Drawings. All hardware replaced with new. Cowl re-assembled and finished with epoxy primer and paint as needed. Fuel Tanks and oil tanks cleaned and inspected for leaks. Performed apressure test and passed. Finished with epoxy primer and paint as needed. All fuel and oil lines were made new. Installed new fuel selector PN:FS30-T6CJ. Installed overhauled wobble pump PN:D-3 SN:46900-1 performed by S&T Aircraft Accessories Inc. CRS#CC2R737K WO:51381. Installed Airwolf Oil Filter Kit PN:AFC-K015-C. Installed overhauled Oil Cooler PN:U-3160 SN:21670. Overhaul performed by Pacific Oil Cooler Service Inc. CRS#RF3R813L WO:124315.
