- Total time
- 8,783 hr
- Year
- 2003
- Serial
- PCE-JA0224
Specifications
Airframe
- Total time ·
- 8,783.2 hr
- MSN ·
- PCE-JA0224
Performance (across variants)
- Range ·
- 1,900 nm
- Cruise ·
- 430 kt
- Service ceiling ·
- 43,000 ft
- MTOW ·
- 10,200 kg
- Passengers ·
- Up to 8
Description
Airframe Maintenance Avionics Total Time Since New 8,783.2 hours Total Landings Since New 8,019 landings Certificate of Airworthiness Date August 27th, 2003 Home Base U.S.A. Maintenance Tracking CAMP Certification Part 135 Current Tail Number N675UP Inspections Last Performed Next Due IFA-A Inspection (12MOS/400 hours) Feb. 2026 Feb 2027 or 302.5 hours IFA-B Inspection (800 hours) Feb. 2026 702.5 hours IFA-C Inspection (1600 hours) Feb. 2026 1,502.5 hours IFA-D Inspection (3200 hours) Apr. 2024 1,635.6 hours Engine #1 Overhaul - - Engine #2 Overhaul - - System Collins Pro Line 4 Type of Unit Description EFIS (Electronic Flight Instrument System) Three Collins Displays FMS (Flight Management System) Dual Collins FMC-5000 GPS (Global Positioning System) Dual Collins GPS-4000S w/ SBAS ADC (Air Data Computer) Dual Collins ADC-850D NAV (Navigation Radio) Dual Collins VIR-432 DME (Distance Measuring Equipment) Dual Collins DME-442 VHF COM (Very High Freq. Communication) Dual Collins VHF-422C RAD ALT (Radar Altimeter) Collins ALT-1000 XPNDR (Transponder) Dual Collins TDR-94D TCAS (Traffic Collision Avoidance System) Collins TTR-4000 TCAS II ver. 7.0 CVR (Cockpit Voice Recorder) L3Harris FA2100 ELT (Emergency Locator Transmitter) Artex C406-2
