Specifications

Description

AIRFRAME AND ENGINES AVIONICS INTERIOR EXTERIOR Additional Equipment Times Current as of Oct. 23, 2017 Airframe Total Time: 5,074 Hrs. Landings: 2,778 Engine Total Time: 5,032 5,032 Engine Total Cycles: 2,759 2,759 Engines enrolled on Rolls Royce Corporate Care (RRCC) Both engines midlife inspection completed: 10/8/2014 APU – Honeywell GTCP36-150G APU APU Total Time: 4,055 Hrs. APU enrolled on Honeywell MSP GOLD UPGRADES CURRENTLY IN PROCESS AT DUNCAN AVIATION: Weight and Balance Engine Preservation Battery charge AVIONICS: Honeywell SPZ-8400 Avionics Suite Triple Honeywell NZ-2000 FMS Honeywell Heads Up Display Dual Collins VIR-432 Nav Radios Triple Collins VHF-422C Comm Radios Dual Honeywell AZ-810 ADCs Dual Honeywell HG2021 GPS Sensors Triple Honeywell HG1075AE LaserRef II IRS Single ACSS TR-951 TCAS II w/7.1 Honeywell MCS-7000 SATCOM (FAX)w/AFIS Dual HF-9034A HF Comm Radios Dual TDR-94D ATC Transponders – Enhanced Surveillance UPGRADES CURRENTLY IN PROCESS AT DUNCAN AVIATION: FMS 6:1 Upgrade (ASC477A) ADSB-Out Version 2 (ASC502) FANS 1A Optional FANS 1A + Printer 2018 – To be Delivered with All New Soft Goods by Duncan Aviation including: new foam and recovering of seats & divan, new carpet, upper and lower sidewalls and PSU & baggage panels. The cabin is configured for 14 passengers. Across from the main entrance door is the crew refreshment center featuring a Prepco and cup dispenser, followed by a crew lavatory. The forward portion of the main cabin consists of a four (4) place club, followed by a left-hand two (2) place club opposite a four (4) place divan in the mid-cabin. The aft cabin features a left-hand four (4) place conference grouping with a mechanical table that opposes a right-hand credenza. Aft of the pocket door is the main galley featuring two coffee machines, microwave oven, convention oven, sink, full cabin controls and storage on the left-hand side. The right-hand side of the galley features two (2) ice drawers, thermos-electric cooler and storage. Aft of the galley is the full lavatory with toilet and sink followed by the baggage compartment. UPGRADES ARE AS FOLLOWS: Replace Cabin Carpet Recover Single Seats – Qty 6 New Foam New foam, seatbelts included Recover Double Conference Seats – Qty 2 New foam, seatbelts NOT included Recover Divan New foam, seatbelts NOT included Recover PSU – Valance Panels Recover Continuous Upper Sidewalls Recover Fabric Lower Sidewalls Recover Baggage Panels and Throw Out Panel Interior Removal and Reinstallation Certification Vertical Burn Dynamic Seat Regulations/Fireblock 2018 – To be Delivered with Brand New paint by Duncan Aviation AS FOLLOWS: Exterior Paint – 2 Stripe Includes erosion boots, entrance/baggage door frames, Step tread, light lense polish, bright work polish Paint wheels Aircell® ATG-5000 Wifi Airshow 4000 w/Three External Cameras Precise Flight Pulselite System Artex® C406-N, Three Frequency, ELT SecuraPlane Security System Honeywell AIS-2000 – Direct TV 20” Bulkhead LCD Monitor 17” LCD Monitor above credenza six (6) LCD Monitors at seats Talon LED Landing Lights CURRENTLY BEING COMPLETED BY GULFSTREAM: FANS-1A Optional FANS 1A+ Printer ADSB-OUT Version 2 FMS 6.1 Upgrade
