Citation S/II

Description

Active Year of Model: 1984 Max Cruise Speed:411 KTAS Number of passengers: 8 Travel range: 1,572 nm N/A S/N S550-0013 GALLERY OVERVIEW The Citation S/II or Super II is the enhanced version of the Classic Citation II 550, as it gained a supercritical airfoil with swept wing-roots, aileron and flap gap seals, and a fluid deicing system instead of the pneumatic deicing boots used on earlier Citations 500,501,550’s.To further reduce drag, the fuselage and engine nacelle pylons were redesigned, and nacelle fairings were added as well. Fuel capacity was increased by 120 US gal (450 L). The result of the improvements was a cruise speed of 411ktas, and a range of 1,500+ with six passengers and crew with fuel reserve. The improved 2,500lbs thrust JT15D-4B engines have higher temperature-rated components, allowing more thrust at higher altitudes. This aircraft features Garmin COMM/NAV-GPS, XM Datalink, ADS-B Trans, Honeywell MFD, TCAS & TAWS, along with Freon A/C and Increased Gross Weight Mod. Contact us today for more details or to schedule a viewing. Highlights Fresh “0” hrs Since HSI/HOTS Garmin GNS-530 | GDL-49 Data Link Honeywell KMD-850 | KGP-560 TAWS Keith Freon A/C | Gross Weight Mod Airframe Hours Since New 11,460 Landings Since New 11,069 Engines Pratt & Whitney JT15D-4B Left Right Serial Numbers PCE71063 PCE102026 Hours Since New 6,270 11,286 Cycles Since New 3,909 10,673 Hours Since HSI/HOTS 0 0 Hours Since Overhaul 2,774 2,827 Overhaul Due TBO 3,500 3,500 Inspection Maintenance Tracking via CAMS Phase 1-4 (24m/300-Hour) – C/W In Process Phase 5 (36m/1,200-Hour) – C/W In Process Eng. 1 & Eng. 2 HSI by Hale Aircraft 2025 Avionics Collins Pro-Line II ADF: Dual Collins ADF-60 Autopilot: Honeywell SPZ-200 IFCS Communication Radios: Collins VHF-22A/ GNS-530 CVR: Fairchild GA 100 DME: Dual Collins DME4 Flight Director: Honeywell SPZ-200 IFCS GPS: Garmin GNS-530 / King KLN-900 Coupled Navigation Radios: Collins VIR-32/ GNS-530 RMI: Dual Collins RMI-30 Stormscope: BFGoodwrich WX-1000+ SATCOM: Aircell ST-3100 w/ Dual Handsets TAWS: Honeywell KGP-560 EGPWS TCAS: Honeywell TPU-66A TCAS-I Transponder: Dual Garmin GTX-345R Transponder (ADS-B out) Weather Radar: Honeywell ART-2100VP Color Radar Additional Information INTERIOR Eight-Passenger Executive Cabin This Citation SII features a nine-passenger executive configuration, seating in Light Grey leather, Aft cabin 4-place club with dual executive tables and forward 4-place club at entry and private aft-belted flushing lavatory. Wilsonart Burlwood veneer and trim with aluminum hardware. Matching light grey leather side walls, formed light texture headliner, and grey multi-line stone pile carpeting. Pyramid low-profile storage compartment mid cabin and 110v outlets in cabin EXTERIOR The aircraft is finished in Matterhorn White with Jade-Mist Green, Kelly Green, Kingston Grey and Dark Gery accent striping. The exterior paint was completed in 2002 by Sky Harbor. WEIGHTS/CAPACITY Max Takeoff Weight: 15,100 lbs Max Ramp Weight: 15,300 lbs Max Landing Weight: 14,500 lbs Zero Fuel Weight: 10,950 lbs Usable Fuel: 5,775 lbs Fuel Capacity: 862 US gal CAPABILITIES RVSM ADS-B W/ Datalink Terrain Awareness Warning Traffic Collision Avoidance ADDITIONAL EQUIPMENT This Citation SII is equipped with Artex 406 ELT, Garmin GNS-530 COMM/NAV-GPS, GAD-42 Adapter, GDL-49 Data-link, Honeywell KGP-560 EGPWS, Honeywell KDR-510 flight information system w/WX uplink, Teledyne angle of attack, Honeywell KMD-850 multi-function display (Weather-NEXRAD, Traffic, Terrain) Collins audio panels, J.E.T. standby gyro, battery temperature monitor, standby gyro, digital fan speed indicators, dual Davtron clocks, Thrust reversers, gross weight increase mod, improved 8.5 gallon TKS system, Sierra Radome mod, engine fan & turbine synch, baggage compartment mod.
