TOP PROP PERFORMANCE CONVERSIONS
Piper PA-31P Pressurized Navajo · Specifications
Overview
This document provides specifications for the Piper PA-31P Pressurized Navajo and the PA-31P-350 Mojave aircraft models. It details the propeller options available for each model, including part numbers and specifications for the engines used. The document is intended for aircraft owners and maintenance personnel who need to understand the propeller options and specifications for these specific aircraft models. It includes information on the propeller diameter, weight, and time between overhaul (TBO) requirements, as well as installation and balancing services offered by Hartzell Propeller Inc.
- PA-31P uses a 93.5 inch diameter propeller; PA-31P-350 uses an 80 inch diameter propeller.
- Both models have a TBO of 2400 hours or 6 years.
- The PA-31P propeller weighs 93 pounds; the PA-31P-350 propeller weighs 88 pounds.
- Diameter reduction for PA-31P is allowable to 93 inches; no reduction for PA-31P-350.
- Installation and dynamic balancing services are available for an additional charge.
Document
Source
Originally published by hartzellprop.com. Sprinkle hosts a reference copy with an added summary, specifications and searchable full text.
Document details
- Type
- Specifications
- Year
- 2019
- Pages
- 2
- File size
- 123 KB
- Publisher
- hartzellprop.com
Specifications & performance
Extracted from this document.
Specifications
- Propeller
- HC-C3YN-2LUF/FJC9684-3R
- Engine model
- TIGO-541-E
Common. One of the most common aircraft types we track.
Most owners only have the POH. Here's the essential set for the Piper PA-31P Pressurized Navajo.
- Pilot's Operating Handbook / AFM
- Checklist
- Maintenance Manual
- Parts Catalog (IPC)
- Systems & Wiring
- Service Bulletins
- Type Certificate (TCDS)
Piper PA-31P Pressurized Navajo for sale now
Free — save the PA-31 to your watchlist and track it in one place.
More Piper PA-31P Pressurized Navajomanuals & documents
- Customer Service Information FileChecklist
- CUSTOMER SERVICE INFORMATION FILEAvionics Manual
- PMA Application and Pump Cross ReferenceParts Catalog
- Airworthiness Concern SheetOther Documents
- REAR HEATER INSTALLATION INSTRUCTIONS FOR HEATER KIT, P/N CD12031K9Weight And Balance
- Piper Pressurized NavajoPilot's Operating Handbook
- Comment-Response Document 2014-24Training Manual
- SERVICE BULLETIN NO. 991AService Bulletins
- PIPER PARTS CATALOGChecklist
- Performance Data for the Piper PA-31P Pressurized NavajoPerformance Data
- Technical Sheet: Piper PA-31-310/325: Navajo, Navajo CRSpecifications
If you fly the Piper PA-31P Pressurized Navajo, you may also be researching these.
In this document
Applicable Models
The document specifies that it applies to the Piper PA-31P with Lycoming TIGO-541-E engines and the PA-31P-350 with Lycoming TIO-LTIO-540V2AD engines.
Propeller Specifications
For the PA-31P Pressurized Navajo, a 93.5 inch diameter 3-bladed aluminum hub propeller is specified, with a time between overhaul (TBO) of 2400 hours or 6 years, and a weight of 93 pounds. A diameter reduction to 93 inches is allowable. For the PA-31P-350 Mojave, an 80 inch diameter 3-bladed aluminum hub propeller is specified, also with a TBO of 2400 hours or 6 years, but weighing 88 pounds, with no diameter reduction permitted.
Installation and Pricing
The document notes that prices are FOB Hartzell Propeller Inc. and do not include Ohio State Sales Tax. Installation and dynamic balancing services are available at an additional charge.
Full document text
T O P P R O P P E R F O R M A N C E C O N V E R S I O N S Piper PA31P Pressurized Navajo and PA31P-350 Mojave Basic Kit: P A31P with TIGO-541-E Engines Part Number: C3N00100STP 2 ea. 3-Bladed Propeller: HC-C3YN-2LUF/FJC9684- 3R Part Number: C3N00150STP Boot ed 2 ea. 3-Bladed Propeller: HC-C3YN-2LUF/FJC9684B-3R Spinners: NOT INCLUDED Basic Kit: P A31P-350 with TIO-LTIO-540V2 AD Engines Part Number: I3R00015STP/I3R00045STP 1ea. 3-Bladed Propeller: HC-I3YR-2UF/ FC7854 HC-I3YR-2LUF/FJC-7854 Part Number: I3R00016STP/I3R00046STP Boot ed 1 ea. 3-Bladed Propeller: HC-I3YR-2UF/ FC-7854K HC-I3YR-2LUF/FJC-7854K Spinners: NOT INCLUDED __________________________________________________________________________________________________ Aircraft Serial and registration numbers required when ordering All Prices FOB Hartzell Propeller Inc. Prices do not include Ohio State Sales Tax Installation and Dynamic Balancing available at an additional charge Telephone: (937) 778-5726 Option 2 / (800) 942-7767 Option 2 Fax: (937) 778-4215 Internet: www.hartzellprop.com Email: topprop@hartzellprop.com T O P P R O P P E R F O R M A N C E C O N V E R S I O N S PIPER Pressurized Navajo, Mojave Applicable Models: PA-31P with Lycoming TIGO-541-E engines. PA31P-350 with Lycoming TIO-LTIO-540V2AD engines. Note: Price does not include spinner assemblies. Specifications: PA31P Pressurized Navajo 93.5 inch diameter 3-bladed aluminum hub propeller 2400 hour / 6 year TBO 93 pounds (propeller) Diameter reduction allowable to 93 inches PA31P-350 Mojave 80 inch diameter 3-bladed aluminum hub propeller 2400 hour / 6 year TBO 88 pounds (propeller) No reduction permitted Replaces: N/A Advantages: Original Equipment - Best value Proven performance, durability, and reliability Top Prop Warranty to first overhaul (6yr/2400 hr) Hartzell worldwide service network March ’19 MCT
