Overview
The AVIAT HUSKY A-1B is a single-engine piston airplane from Aviat (some bulletins carry the Sky International name). The supplied data has no variant-specific specs or performance figures, so this guide covers the service bulletins that affect the A-1B. Check each one against the logbooks before you buy.
- The Husky family (A-1 to A-1C-200) is listed at up to 2 passengers, 150 kt cruise, 900 nm range and a 26000 ft ceiling. These are family maxima, not A-1B figures.
- SB 34 is a mandatory stabilizer support assembly inspection and covers all A-1B serial numbers. Aircraft with over 1200 hours had broken parts.
- SB 28 requires inspection of the rear stabilizer support tube before next flight and every 100 hours or at annual inspection.
- Confirm SB 21 (flap link, S/N 2397-2418) and SB 24 (drain valve, Lycoming IO-360-A1D6) were done where they apply.
Summary written by AI from the source document. Check the original before relying on it. See which parts of Sprinkle are written by AI.
Reference only, not for flight. Use the current approved manual for your aircraft. See terms, section 5.
Document
Source
Copy found at sprinkle.com. Sprinkle hosts a reference copy with an added summary, specifications and searchable full text.
Document details
- Type ·
- Model Guide
- Year ·
- 2026
- File size ·
- 49 KB
- Copy found at ·
- sprinkle.com
Specifications & performance
Extracted from this document.
Performance
- Max range (nm) ·
- 900
- Max cruise speed (kt) ·
- 150
- Max service ceiling (ft) ·
- 26,000
Is there a mandatory inspection on the AVIAT HUSKY A-1B?
Yes. For the AVIAT HUSKY A-1B, SB 34 requires a stabilizer support assembly inspection per AD 2020-16-06, and it affects all serial numbers. SB 28 also requires inspection of the rear stabilizer support tube.
Which AVIAT HUSKY A-1B serial numbers are affected by the flap link bulletin?
SB 21 affects AVIAT HUSKY A-1B serial numbers 2397-2418. The flap cable link should measure 0.100 inch thick, and kit A-1B-521 replaces a defective one.
Does the AVIAT HUSKY A-1B need a drain valve?
SB 24 requires a Drain Valve Assembly on listed AVIAT HUSKY A-1B serial numbers fitted with the Lycoming IO-360-A1D6 engine. This prevents over-priming and flooding.
What is the AVIAT HUSKY A-1B Model Guide?
The AVIAT HUSKY A-1B Model Guide is a model guide for the AVIAT HUSKY A-1B, dated 2026.
What year was the AVIAT HUSKY A-1B Model Guide published?
The AVIAT HUSKY A-1B Model Guide — the AVIAT HUSKY A-1B model guide on file — is dated 2026.
Common. More common than 96% of the aircraft models we track.
Most owners only have the POH. Here's the essential set for the AVIAT HUSKY A-1B.
- Pilot's Operating Handbook / AFM
- Checklist
- Maintenance Manual
- Parts Catalog (IPC)
- Systems & Wiring
- Service Bulletins on file
- Type Certificate (TCDS)
AVIAT HUSKY A-1B for sale now
Free — save the A-1 to your watchlist and track it in one place.
More AVIAT HUSKY A-1Bmanuals & documents
Related documents
- AVIAT HUSKY A-1C-180 Model GuideAVIAT HUSKY A-1C-180 · Model Guide
- AVIAT HUSKY A-1 Model GuideAVIAT HUSKY A-1 · Model Guide
- AVIAT HUSKY A-1C-200 Model GuideAVIAT HUSKY A-1C-200 · Model Guide
- Service Bulletin No. 25AVIAT HUSKY A-1 · Service Bulletins
- Service Bulletin No. 34AVIAT HUSKY A-1B · Service Bulletins
If you fly the AVIAT HUSKY A-1B, you may also be researching these.
In this document
Tail structure inspections (SB 34, SB 28)
SB 34 (Rev C, 25 Sep 2020) refers to AD 2020-16-06 and requires a crack inspection of the stabilizer support assembly, P/N 35086-501 or 38086-501. Cracks started at the toe of the welded bushings. SB 28 covers rear support tube P/N 30800-111 on A-1B S/N 2397 and below, with inspection before next flight and every 100 hours or at annual. Ask for logbook entries and the compliance letters.
Flap cable link (SB 21)
SB 21 applies to A-1B S/N 2397-2418. One link, P/N 35064-001, was made from 0.050 inch stock instead of the required 0.100 inch. Buyers should check that the link measures 0.100 inch, or that it was replaced under Kit A-1B-521. The bulletin asks for a compliance letter even if the part was good.
Engine drain valve and battery
SB 24 calls for a Drain Valve Assembly on A-1B and A-1C aircraft with the Lycoming IO-360-A1D6 engine. It lists specific A-1B serial numbers and aims to prevent over-priming and flooding when the engine is idle. Check that it was installed and logged. EarthX's ETX900-TSO battery manual has an Aviat install appendix, so ask whether a lithium battery is fitted.
Summary written by AI from the source document. Check the original before relying on it. See which parts of Sprinkle are written by AI.
Safety notes
- SB 34 is mandatory. A broken stabilizer support assembly was found on pre-flight inspection of aircraft with over 1200 hours.
- Only FAA certified mechanics should do the SB 34 inspection and the SB 28 repair.
- If an EarthX lithium battery is fitted, the manual requires a separate automatic over-voltage protection device for alternator charging systems.
Summary written by AI from the source document. Check the original before relying on it. See which parts of Sprinkle are written by AI.
