Type Certificate Data Sheet
CESSNA 337G · Type Certificate
Overview
This document serves as a Type Certificate Data Sheet (TCDS) for the Cessna 336 and 337 series aircraft, including the Cessna 337G. It outlines the certification details, applicable aircraft models, and specifications for the propeller system approved under FAA STC # SA02460AT. The document is intended for aircraft owners, maintenance personnel, and operators who require detailed information regarding the propeller installation and specifications for these aircraft models. It includes information on the propeller type, specifications, and advantages over existing propellers, ensuring compliance with safety and performance standards.
- The document is a Type Certificate Data Sheet for Cessna 336/337 series aircraft, including the 337G.
- It includes specifications for the MTV-12-D-C-F/CF(LD)192-119a propeller with a diameter of 75.6 inches.
- The propeller system is designed to replace existing McCauley propellers, offering reduced weight and improved vibration damping.
Summary written by AI from the source document. Check the original before relying on it. See which parts of Sprinkle are written by AI.
Reference only, not for flight. Use the current approved manual for your aircraft. See terms, section 5.
Document
Source
Copy found at www.mt-propellerusa.com. Sprinkle hosts a reference copy with an added summary, specifications and searchable full text.
Document details
- Type ·
- Type Certificate
- Year ·
- 2022
- Pages ·
- 1
- File size ·
- 76 KB
- Copy found at ·
- www.mt-propellerusa.com
Specifications & performance
Extracted from this document.
Specifications
- Propeller ·
- MTV-12-D-C-F/CF(LD)192-119a
- Engine model ·
- Teledyne Continental Motor (TS)IO-360-( )
What is the Type Certificate Data Sheet?
The Type Certificate Data Sheet is a type certificate for the CESSNA 337G, dated 2022.
How many pages is the Type Certificate Data Sheet?
The copy of the Type Certificate Data Sheet on file runs 1 pages.
What year was the Type Certificate Data Sheet published?
The Type Certificate Data Sheet — the CESSNA 337G type certificate on file — is dated 2022.
Common. More common than 95% of the aircraft models we track.
Most owners only have the POH. Here's the essential set for the CESSNA 337G.
- Pilot's Operating Handbook / AFM
- Checklist
- Maintenance Manual
- Parts Catalog (IPC)
- Systems & Wiring
- Service Bulletins on file
- Type Certificate (TCDS)
CESSNA 337G for sale now
Free — save the 337 to your watchlist and track it in one place.
More CESSNA 337Gmanuals & documents
See all 15 →- CESSNA 337G Model GuideModel Guide
- FUEL - FUEL STRAINER INSPECTIONMaintenance Manual
- R1224 REGULATOR INSTALLATION INSTRUCTIONS P/N 12-1001Wiring Diagrams
- Type Acceptance Report - TAR 17/21B/26 - CESSNA F337 SeriesOther Documents
- Airworthiness Directive Schedule Aeroplanes Cessna 337 SeriesService Bulletins
- Type Acceptance Report TAR 18/21B/4 – Cessna 337 SeriesOther Documents
- AD/CESSNA 337/31 Alternate Static Air Source Selector Valve PlacardService Bulletins
- AD/CESSNA 337/30 Pitot Tube InstallationSupplemental Type Certificate
- AIRWORTHINESS DIRECTIVE AD/CESSNA 337/22 Amdt 3Airworthiness Directives
- Airworthiness Directives; Cessna Aircraft Company 120, 140, 140A, 150, F150, 170, 172, F172, FR172, P172D, 175, 177, 180, 182, 185, A185E, 190, 195, 206, P206, U206, TP206, TU206, 207, T207, 210, T210, 336, 337, and T337 Series AirplanesAirworthiness Directives
- AWB 27-3 Issue 1, Cessna 336/337 Flap Cable WearService Bulletins
- Airworthiness Directive AD/CESSNA 337/28 Fuel StrainerService Bulletins
Related documents
- Propeller STC Kit Contents and SpecificationsCessna 336 Skymaster · Pilot's Operating Handbook
- Airplane Flight Manual SupplementCessna 335 · Flight Manual
- Airplane Flight Manual SupplementCessna 340 · Flight Manual
- Flyer No.: FL-128Cessna 182 Skylane · Supplemental Type Certificate
- Supplemental Type Certificate for Piper PA-30, PA-39 (Twin Comanche)Piper PA-30 Twin Comanche · Supplemental Type Certificate
If you fly the CESSNA 337G, you may also be researching these.
In this document
Applicable Aircraft
The TCDS applies to a range of Cessna aircraft models including the Cessna 336, 337, and various sub-models such as 337A through 337H, as well as T337 and P337 variants. This broad applicability ensures that the information is relevant to a wide audience of Cessna operators.
Propeller Specifications
The document details the specifications of the MTV-12-D-C-F/CF(LD)192-119a propeller, which includes a maximum and minimum diameter of 75.6 inches. The propeller is made from a lightweight natural composite material and features a milled single-piece aluminum hub.
Installation Instructions
Included in the STC kit are installation instructions and an operation manual that provide guidance on the proper installation and operation of the propeller system, ensuring compliance with FAA regulations.
Summary written by AI from the source document. Check the original before relying on it. See which parts of Sprinkle are written by AI.
Full document text
MT-Propeller Entwicklung GmbH Flugplatzstr. 1 94348 Atting / Germany Phone: +49 (0) 9429 9409 0 Fax: +49 (0) 9429 8432 sales@mt-propeller.com MT-Propeller USA, Inc. 1180 Airport Terminal Drive DeLand, Florida 32724 Phone: (386) 736-7762 Fax: (386) 736-7696 info@mt-propellerusa.com Certification # EASA.21J.020, DE.21G.0008 www.mt-propeller.com Certified FAA Repair Station No. Q4MR908Y Flyer No.: FL-009 February 07, 2022 Type of Aircraft: Cessna 336/337 FAA STC #: SA02460AT (Last Amendment: December 14, 2017) Aircraft TCDS #: A2CE (336) / A6CE Propeller TCDS #: P25NE Applicable Aircraft Cessna 336, 337, 337A, 337B, M337B, 337C, 337D, 337E, 337F; 337G; 337H; T337B, T337C, T337D, T337E, T337F, T337G, T337H, P337H, T337H-SP; Engine Teledyne Continental Motor (TS)IO-360-( ) according aircraft TCDS STC Kit Contents Two 3-Blade Constant Speed Propeller MTV-12-D-C-F/CF(LD)192-119a Two Full Composite Spinner (AFRP) P-615 One Airplane Flight Manual Supplement 2002-1; 2003-1 One Installation Instruction Doc. No. C336/337P-99-01 Rev. A One Operation and Installation Manual ATA 61-01-24 (E-124) Propeller Specifications Full Propeller Designation MTV-12-D-C-F/CF(LD)192-119a Propeller Hub MTV-12-D-C-F Milled single-piece aluminum hub Blade CF(LD)192-119a Blade Design Light-weight natural composite Both installed Propellers & Spinner Weight 110 lbs Maximum Diameter 75.6 in. Minimum Diameter 75.6 in. TBO According to SB 1 ( ) latest issue Replaces All existing McCauley propellers Advantages • Best vibration damping characteristics for almost vibration free propeller operations! • Bonded on stainless steel leading edge for best erosion protection of the blades! • Performance remains unchanged! • Approx. 15 lbs less weight than the original propellers! • Unlimited blade life! • Significant inside and outside noise reductions!
