Piper Arrow IV manuals
Pilot's operating handbook, checklist, flight manual and related references for the Piper Arrow IV.
Documentation completeness
1/7
Most owners only have the POH. Here's the essential set for the Piper Arrow IV.
- Pilot's Operating Handbook / AFM
- Checklist
- Maintenance Manual
- Parts Catalog (IPC)
- Systems & Wiring
- Service Bulletins on file
- Type Certificate (TCDS)
Piper Arrow IV manuals & documents
1 document for the Piper Arrow IV — Systems Description. PDFs served from cdn.sprinkle.com.
Overview
Piper Arrow IV Landing Gear System Operation Overview · 2016
This document provides an overview of the Piper Arrow IV's landing gear system, detailing its operation, indicators, and emergency procedures. It covers the normal retraction and extension processes, as well as the automatic gear extension system and manual emergency extension procedures.
- Landing gear is hydraulically operated with no gear up-locks.
- Emergency extension allows gear to freefall when hydraulic pressure is dumped.
- Normal retraction should not exceed 109 KIAS; extension should not exceed 130 KIAS.
- Automatic gear extension activates below approximately 87 KIAS unless overridden.
- Manual emergency extension is possible by pushing a red lever down.
- The gear warning system activates under specific low power conditions.
- Hydraulic pressure loss may trigger the hydraulic pump to activate.
- Maintenance should be contacted if the hydraulic pump runs during cruise.
