Exhaust Systems Engine Mounts Carb Air Boxes
CESSNA 182S SKYLANE · Systems Description
Overview
This document serves as a parts catalog for the Cessna 182S Skylane and Cessna 182T Skylane aircraft. It provides detailed information on various components related to the exhaust systems, engine mounts, and carburetor air boxes. The catalog includes part numbers and descriptions for each component, making it a valuable resource for maintenance and repair. It is intended for use by aircraft maintenance personnel and parts suppliers to ensure proper servicing of these aircraft models.
- Muffler assembly part number: 9954200-9
- Right hand shroud assembly part number: 9954200-8
- Left hand shroud assembly part number: 9954200-7
- Inspect tailpipes for internal pitting and wall thickness
- Engine mount part number: 2251000-27
Document
Source
Originally published by www.acornwelding.com. Sprinkle hosts a reference copy with an added summary, specifications and searchable full text.
Document details
- Type
- Systems Description
- Year
- 2010
- Pages
- 1
- File size
- 166 KB
- Publisher
- www.acornwelding.com
Common. Rarer than 3% of the aircraft models we track.
Most owners only have the POH. Here's the essential set for the CESSNA 182S SKYLANE.
- Pilot's Operating Handbook / AFM
- Checklist
- Maintenance Manual
- Parts Catalog (IPC)
- Systems & Wiring
- Service Bulletins
- Type Certificate (TCDS)
CESSNA 182S SKYLANE for sale now
Free — save the 182S Skylane to your watchlist and track it in one place.
More CESSNA 182S SKYLANEmanuals & documents
- C182 Systems - FAA SafetySystems Description
- CESSNA 182S SKYLANE PERFORMANCE DATAPerformance Data
- VISUAL INSPECTION - Cessna Flyer AssociationService Bulletins
- SKYLANE 182T - Tropical Aviation DistributorsAvionics Manual
- Floatplane Source Noise Measurements Summary of Measurements, Data and Analyses for the Cessna 182S Skylane and De Havilland Canada DHC-2 BeaverPerformance
- AAIB Bulletin No: 4/2003Other Documents
- Airworthiness Approval Note - Civil Aviation AuthorityType Certificate
- Cessna 182S Skylane N965CWChecklist
- Cessna 182S Skylane ChecklistChecklist
- section 6 - weight and balance/equipment list model 182t nav iiiWeight And Balance
If you fly the CESSNA 182S SKYLANE, you may also be researching these.
In this document
Exhaust System Components
The catalog lists various components of the exhaust system, including mufflers, shrouds, and tailpipes. Each part is identified by a unique part number, such as the MUFFLER ASSY (part number 9954200-9) and SHROUD ASSY (part numbers 9954200-8 for right hand and 9954200-7 for left hand).
Inspection Guidelines
Important inspection guidelines are provided for the exhaust system components. For instance, the muffler requires baffles to be serviceable, and tailpipes should be inspected for internal pitting and wall thickness, particularly at the outside radius. Additionally, the collector just before the ball joint should be checked for heat distortion and black flaking material.
Part Numbers and Descriptions
The document includes a comprehensive list of part numbers and their descriptions, such as the ENGINE MOUNT (part number 2251000-27) and various clamps and gaskets. This information is crucial for ordering the correct parts during maintenance.
Safety notes
- Muffler requires baffles to be serviceable.
- Inspect tailpipes for internal pitting and wall thickness, especially at the outside radius.
Full document text
Exhaust Systems Engine Mounts Carb Air Boxes Shrouds Seats Piston Turbine Radial Vintage And More... L E L N E C C E X E Item Part Number Description 9954200-9 MUFFLER ASSY RIGHT & LEFT HAND 9954200-8 SHROUD ASSY RIGHT HAND 9954200-7 SHROUD ASSY LEFT HAND 9954200-6 STACK ASSY EXHAUST RIGHT HAND 9954200-5 STACK ASSY EXHAUST LEFT HAND 9954200-12 TAILPIPE RIGHT HAND 9954200-11 TAILPIPE LEFT HAND 0750161-22 CLAMP HALF 1254007-1 CLAMP HALF 2254000-1 RISER 77611 GASKET 011-250 SPRING KIT 2251000-27 ENGINE MOUNT J-23508-1 SHOCK MOUNT 0514214-29 SEAT FRAME BOTTOM 1 2 3 4 5 6 7 8 9 10 - - - - - Muffler requires baffles to be serviceable. Inspect tailpipes for internal pitting and wall thickness especially at the outside radius, which is the thin section, and at support bracket. 8 9 7 1 2 3 4 6 5 9 8 1 10 10 Inspect collector just before the ball joint for heat distortion and black flaking material. CESSNA 182S Skylane CESSNA 182T SkylaneAircraft Produced After 1997 SN 80000 - 80286 SN 80287 and on (toll free) 1-888-388-8803 1-780-447-5955 Fax: 1-780-447-5980 sales@acornwelding.com parts@acornwelding.com www.acornwelding.com (toll free) 1-888-388-8803 1-780-447-5955 Fax: 1-780-447-5980 sales@acornwelding.com parts@acornwelding.com www.acornwelding.com ©2010 Acorn Welding Ltd.
