CESSNA CARAVAN 208 FLOATPLANE · Performance Data
Overview
This document provides performance data for the Cessna 208 Caravan, a versatile turboprop aircraft known for its rugged utility and adaptability to various missions. It includes specifications such as maximum range, cruise speed, and useful load, along with detailed mission profiles and fuel consumption data. The Caravan is powered by a PT6A-114A turbine engine, which enhances its payload capabilities and operational efficiency. This performance data is essential for pilots and operators to understand the aircraft's capabilities under standard conditions, ensuring safe and efficient flight planning.
- Max Range: 1,070 nm (1,982 km)
- Max Cruise Speed: 186 ktas (344 km/h)
- Useful Load: 3,305 lb (1,499 kg)
- Takeoff Ground Roll: 1,160 ft (354 m)
- PT6A-114A Engine: 675 shp
Document
Source
Originally published by cessna.txtav.com. Sprinkle hosts a reference copy with an added summary, specifications and searchable full text.
Document details
- Type
- Performance Data
- Year
- 2025
- Pages
- 8
- File size
- 2.7 MB
- Publisher
- cessna.txtav.com
Specifications & performance
Extracted from this document.
Specifications
- Range (nm)
- 1,070
- Engine (hp)
- 675
- Engine model
- PT6A-114A
- Max speed (kt)
- 186
Performance
- Takeoff distance (ft)
- 1,160
Weight & balance
- Useful load (lb)
- 3,305
Common. One of the most common aircraft types we track.
Most owners only have the POH. Here's the essential set for the CESSNA CARAVAN 208 FLOATPLANE.
CESSNA CARAVAN 208 FLOATPLANE for sale now
Free — save the 208 to your watchlist and track it in one place.
More CESSNA CARAVAN 208 FLOATPLANEmanuals & documents
See all 36 →- MOSAIC Final Rule Issuance - Federal Aviation AdministrationAirworthiness Directives
- YUKON 208 PROPELLER INSTALLATION GUIDE | WipaireParts Catalog
- 8750-Service-Manual-Rev-U.pdf - WipaireV Speeds Reference
- 2022-2023 Catalog - McFarlane AviationParts Catalog
- service manual - WipairePilot's Operating Handbook
- Product CatalogAvionics Manual
- SERVICE MANUAL & ICA WIPLINE 8000 FLOATS ON CESSNA 208Weight And Balance
- GOODYEAR AVIATION DATA BOOKPerformance Data
- INSTRUCTIONS FOR CONTINUED AIRWORTHINESS FOR AN EXECUTIVE INTERIOR INSTALLATION IN CESSNA AIRCRAFT COMPANY MODELS 208/208BWeight And Balance
- Electric Cessna Caravan Supplemental Type Certificate (STC) programSupplemental Type Certificate
- Electric Cessna Caravan Supplemental Type Certificate (STC) ProgramSupplemental Type Certificate
- Collision with terrain involving Cessna 208 Caravan, VH-WTY - ATSBOther Documents
If you fly the CESSNA CARAVAN 208 FLOATPLANE, you may also be researching these.
In this document
Specifications
The Cessna 208 Caravan has a maximum range of 1,070 nautical miles (1,982 kilometers) and a maximum cruise speed of 186 knots indicated airspeed (344 km/h). It can accommodate 10 to 14 occupants and has a useful load of 3,305 pounds (1,499 kilograms). The takeoff ground roll is 1,160 feet (354 meters).
Mission Profiles
The document outlines mission profiles with estimated times and block fuel requirements for various distances. For example, a 100 nautical mile mission takes approximately 33 minutes with a fuel burn of 256 pounds, while a 500 nautical mile mission takes about 2 hours and 45 minutes with a fuel burn of 1,052 pounds.
Engine Specifications
The Caravan is equipped with a PT6A-114A turbine engine, rated at 675 shaft horsepower (shp). This engine provides the aircraft with exceptional performance and reliability, making it suitable for a wide range of missions.
Avionics Features
The Caravan features advanced avionics including a Garmin G1000 NXi suite, which provides enhanced situational awareness through primary flight displays, multifunction displays, and integrated charts. Optional features include an enhanced automatic flight control system and synthetic vision technology.
Performance Assumptions
Performance data is based on standard day conditions with zero wind, assuming a level, dry, paved runway at sea level and maximum takeoff weight (MTOW).
Safety notes
- Performance data assumes standard conditions; actual performance may vary based on environmental factors.
- Ensure compliance with local aviation regulations regarding maximum occupants.
Full document text
C A R AVA N 1 CARAVAN THE ORIGINAL TRAILBLAZER C E S S N A C A R AVA N 2 SPECIFICATIONS Max Range 1,070 nm 1,982 km Max Cruise Speed 186 ktas 344 km/h Max Occupants* 10-14 Useful Load 3,305 lb 1,499 kg Takeoff Ground Roll 1,160 ft 354 m MISSION TIME BLOCK FUEL 100 nm :33 256 lbs 200 nm 1:07 440 lbs 300 nm 1:39 644 lbs 400 nm 2:12 878 lbs 500 nm 2:45 1,052 lbs A MISSION IN UTILITY AND CAPABILITY The Cessna® Caravan® aircraft is known for its rugged utility and flexibility. With its powerful turboprop engine, the Caravan® aircraft delivers the rare combination of high performance, low operating costs and ability to adapt to a wide variety of missions. The powerful, efficient, ultra- dependable 675-shp PT6A-114A turbine engine gives the Caravan® turboprop its exceptional payload capabilities. On top of more than 40 years of proven capability comes even greater value with this plane’s limited warranties, parts availability and lower direct operating costs. VIEW CARAVAN RANGE MAP Missions shown at HSC, ISA with VFR 45 Minutes Reserve *Dependent on local aviation regulations. Performance data based on a standard day with zero wind. Field performance assumes a level, dry, paved runway, sea level at MTOW. Range based on a ferry mission at LRC with VFR 45 minutes reserve. C A R AVA N 3 C A R AVA N 3 4 S K YC O U R I E R ( F R E I G H T E R ) 5 ULTIMATE CABIN FLEXIBILITY Customize your Caravan® aircraft cabin configuration to match changing mission profiles and optimize revenue on every flight. Highly ergonomic seats with stain-resistant and antimicrobial finished fabric, make for a durable yet versatile interior. Create the picture of your perfect cabin from a palette of interior collections and configurations. ONE AIRCRAFT. EVERY ENVIRONMENT. SEE YOUR MULTI- MISSION OPTIONS C A R AVA N 5 INTELLIGENT FLIGHT DECK ADVANCED AVIONICS Standard Features: • Pilot and Copilot Primary Flight Displays (PFD) • Multifunction Display (MFD) • GDL® 60 Datalink with wireless database uploads and flight plan transfer • GI 275 Electronic Standby Indicator • Dual Attitude and Heading Reference System (AHRS) • Dual Audio System with Bluetooth capability and 3D audio • ADS-B In/Out with Diversity Transponder • Garmin® SafeTaxi • Integrated VFR and IFR Charts • KN-63 DME Optional Features: • Enhanced Automatic Flight Control System • GWX™ 8000 Automatic Weather Radar • Synthetic Vision Technology • Taxiway Routing EXPLORE MORE AVIONICS 6 Enjoy the spacious cockpit powered by the latest technology — Garmin® G1000® NXi avionics suite. Managing the flight deck has never been easier with an improved graphical interface, more powerful hardware, higher-resolution displays and added functionality for increased situational awareness. C A R AVA N 7 SERVICE THAT KEEPS YOU MOVING THE FUTURE OF FLIGHT With the expansive coverage of Textron Aviation aftermarket services, your success is always supported. Whether it’s an upgrade or custom modification, Textron Aviation Service Centers are the known and trusted choice for workmanship, quality and world-class engineering provided by the best in the industry. With cost-per-flight-hour programs, you’re able to increase efficiency and enjoy long-term price protection. And when you need parts, product or field support anywhere in the world, our global support network is available 24/7. Our unparalleled aftermarket service, staffed with hands-on experts, is here for you. At Textron Aviation, we prioritize efficiency and innovation in manufacturing and energy procurement because we’re strongly committed to sustainability. Since 2022, all our Kansas facilities have been powered by 100% renewable wind energy. We’re utilizing more environmentally friendly materials for aircraft interiors. And we’re offering turbine aircraft that can operate with Sustainable Aviation Fuel (SAF), reducing our carbon footprint and helping contribute to a sustainable future for the planet. VIEW OUR GLOBAL SERVICE NETWORK SEE SUSTAINABILITY IN MOTION ©2025 Textron Aviation Inc. All rights reserved. Cessna® and Caravan® are trademarks or service marks of Textron Aviation Inc. or an affiliate and may be registered in the United States or other jurisdictions. Garmin®, G1000®, GDL®, and GWX™ are trademarks and/or service marks of their respective owners. C O N TA C T YO U R T E X T R O N AV I AT I O N R E P R E S E N TAT I V E U . S . + 1 . 8 4 4 . 4 4 .T X TAV I N T E R N AT I O N A L + 1 . 3 1 6 . 5 1 7. 8 2 7 0 T X TAV. C O M / C A R AVA N RELIABLE. VERSATILE. CAPABLE.
