Cessna TTx manuals

Pilot's operating handbook, checklist, flight manual and related references for the Cessna TTx.

Get an email when a Cessna TTx is listed for sale or drops in price.

How rare is it?

143Cessna TTx registered worldwide · 142 active

Common. More common than 80% of the aircraft models we track.

Documentation completeness

3/7

Most owners only have the POH. Here's the essential set for the Cessna TTx.

Pilot's Operating Handbook / AFM
Checklist
Maintenance Manual
Parts Catalog (IPC)
Systems & Wiring
Service Bulletins on file
Type Certificate (TCDS)

Cessna TTx manuals & documents

4 documents for the Cessna TTx — Maintenance Manual · Service Bulletins · Specifications · Model Guide. PDFs served from cdn.sprinkle.com.

Overview

STC Installation Manual & Instructions for Continued Airworthiness - CC Series Fuel Level Sender · 2019

This document serves as the installation manual and instructions for continued airworthiness for the CiES CC Series fuel level sending units, specifically under STC SA02511SE. It is intended for use by aircraft technicians and installers who are responsible for the installation of these fuel senders in eligible aircraft models, including the Cessna TTx. The manual outlines the specifications, installation procedures, electrical requirements, calibration processes, and troubleshooting guidelines necessary to ensure proper functionality and compliance with FAA regulations. It emphasizes the importance of safety during installation and provides detailed instructions to prevent potential hazards such as ignition sources in the event of a lightning strike.

Operating voltage range: 9-28 VDC
Power consumption at 14 VDC: 17.1 mA; at 28 VDC: 9.6 mA
Signal output ranges include frequency (1,200Hz – 490Hz) and voltage (0-5 VDC)
Calibration must ensure accuracy within 3% of actual fuel volume
Proper bonding is critical for installations in metal aircraft to prevent ignition sources.

Summary written by AI from the source document. Check the original before relying on it. See which parts of Sprinkle are written by AI.

Reference only, not for flight. Use the current approved manual for your aircraft. See terms, section 5.

Read the document

Documents are sourced from publicly available references. Sprinkle does not host OEM-restricted materials; if you are a rights-holder and want a document removed, email .
