CANADA FLIGHT SUPPLEMENT

LIGHTING 12-AN(TE HI), 30-AO (non-std 1200') (TE HI) V2 All lgt PN ARCAL-122.2 type K COMM RCO Québec rdo (U) ATF tfc 122.2 5NM 3100 ASL PAL Moncton Ctr 134.25 NAV NDB CL 207 (M) N48 00 31 W66 26 13 CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCS4 CHIPMAN NB CCS4 REF N46 08 55 W65 54 15 2SW 18°W (2014) UTC-4(3) Elev 65´ A5003 RCAP OPR J.D. Irving Woodlands 506-632-7777 Reg PPR PF D-1,2,3,4,5 FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA Rwy 09(090°)/27(270°) 4022x50 asphalt RCR Opr Fld maint May-Oct No win maint. COMM ATF tfc 123.2 5NM 3100 ASL CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCDJ4 CLEARWATER NB CDJ4 REF N46 42 48 W66 49 42 18°W (2013) UTC-4(3) Elev 1330´ A5003 RCAP OPR J.D. Irving Woodlands 506-632-7777 Reg PPR FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. WX WxCam RWY DATA Rwy 14(134°)/32(314°) 3979x60 asphalt Rwy 14 up 1.08% RCR Opr Fld maint May-Oct. No win maint. COMM ATF tfc 123.2 5NM 4300 ASL CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCRM4 CORMIER NB CRM4 REF N46 10 51 W64 22 32 1.1NW 18°W (2015) UTC-4(3) Elev 84’ A5003 OPR George Cormier 902-748-2434 Reg PPR PF C-1,2,3,5 FLT PLN NOTAM FILE CYQM FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) RWY DATA Rwy 08(075°)/26(255°) 3000x80 GRASS RCR Opr COMM ATF tfc 123.2 5NM 3100 ASL CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCDU6 DOAKTOWN NB CDU6 REF N46 33 09 W66 05 38 2.3NE 18°W (2013) UTC-4(3) Elev 326 A5003 RCAP OPR J.D. Irving Woodlands 506-632-7777 Reg PPR PF C-1,2 D-3,4,5,6 FLT PLN NOTAM FILE CYQM FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA Rwy 11(113°)/29(293°) 3998x49 asphalt RCR Opr No win maint COMM ATF tfc 123.2 5NM 3400 ASL CAUTION Ocsl storage tanks 1050' from thld Rwy 29 right side. Tanker operations dur sum months. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCDV2 DOWNS GULCH NB CDV2 REF N47 45 11 W67 25 36 7.5N 18°W (2013) UTC-4(3) Elev 884´ A5003 LO7 LO8 RCAP OPR J.D. Irving Woodlands 506-632-7777 Reg PPR PF D-1,2,3,4,5,6 FLT PLN NOTAM FILE CYCL FIC (bil) Québec 866-GOMÉTÉO or 866-WXBRIEF (Toll free within Canada) or 866-541-4105 (Toll free within Canada & USA). Flt Plns by Fax 418-871-4906 & include phone numbers where pilot can be reached prior to dep. ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA Rwy 05(050°)/23(230°) 4513x60 ASPH Rwy 23 down 0.65%. RCR Opr No win maint COMM ATF tfc 123.2 5NM 3900 ASL CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCYES EDMUNDSTON NB CYES REF N47 29 24 W68 28 54 9NW 18°W (2014) UTC-4(3) Elev 498’ A5002 LO7 LO8 RCAP OPR Aéroport Madawaska Airport Inc 506-737-3878 Reg PF A-1 C-2 D-3,4,5,6 CUST AOE/15 888-226-7277 FLT PLN FIC NOTAM FILE CYCL (bil) Québec 866-WXBRIEF or (French) 866-GOMÉTÉO (Toll free within Canada) or 866-541-4105 (Toll free within Canada & USA). Flt Plns by Fax 418-871-4906 & include phone numbers where pilot can be reached prior to dep. ACC (IFR only) Montréal 514-633-3211 or 800-633-1353. SERVICES FUEL 100LL, JA-1 10-19Z‡ Mon-Fri O/T 506-737-3878 Call out chg may be levied OIL All RWY DATA RCR Rwy 16(152°)/34(332°) 4562x75 ASPH Opr PN for win maint LIGHTING 16-(TE LO) AP, 34-(TE LO) AP ARCAL-122.8 type J COMM ATF UNICOM ltd hrs O/T tfc 122.8 5NM 3500 ASL PRO Rgt hand circuits Rwy 34 (CAR 602.96). Acft that cancel IFR in USA airspace and are unable to file a VFR Flt Pln, must cancel the SAR portion of their IFR Flt Pln for CYES with CZUL ACC at 514-633-3023. CAUTION Only pilots familiar with the lcl area should use this aprt dur hrs of darkness due to surrounding high terrain. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCR3 FLORENCEVILLE NB CCR3 REF N46 25 34 W67 37 41 0.7SW 18°W (2013) UTC-4(3) Elev 508´ A5002 A5003 LO8 HI6 RCAP OPR McCain Foods Ltd 506-392-3800 Reg PPR PF A-1 C-2,3,4,5,6 CUST AOE/15 13-21Z‡ Mon-Fri exc hols 888-226-7277 FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. WX AUTO 506-392-3938 (see COMM) RWY DATA Rwy 18(176°)/36(356°) 5414x100 asphalt Rwy 36 up 0.96% RCR Opr 13-21Z‡ O/T 506-612-0686 Ltd win maint LIGHTING 18-(LO) V2 2.75°, 36-AS(LO) V2 2.75° ARCAL-123.0 for 15 min period, key mic 5 times; 3 times for low ints. COMM ATF tfc 122.8 5NM 3500 ASL AUTO 122.55 PRO Activate ARCAL dur day & night ops. CAUTION Hangar complex E of Rwy 18 thld within 100´ of rwy edge. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCRC2 FREDERICTON (RCMP) NB (Heli) CRC2 REF N45 55 54 W66 40 00 Adj 18°W (2014) UTC-4(3) Elev 369´ A5003 OPR RCMP 506-451-6050 Reg PPR FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. HELI DATA 77´ x 77´ asphalt LIGHTING FL(LO) Arr/dep 330°/150° DR(LO) COMM MF Saint John rdo 119.0 0345-1045Z‡ 5NM 3500 ASL (CAR 602.98) ATF tfc 123.2 5NM 3400 ASL PRO Arr/dep 133°/313° & 330°/150° fr heli. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCYFC FREDERICTON INTL NB CYFC REF N45 52 08 W66 32 14 7SE 18°W (2014) UTC-4(3) Elev 67´ A5003 LO8 HI6 CAP OC OPR Greater Fredericton Airport Authority 506-460-0920 Cert PF A-1,2,3,6(0900-0400Z‡) C-4,5 CUST AOE/55 (140 with staged off-loading) 12-04Z‡ 888-226-7277 FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. WX METAR AUTO H24 WxCam TAF H24, issue times: 00, 06, 12, 18Z. SERVICES Call out chg may be levied for one or more svcs FUEL 100LL, JA-1 (FSII avbl), F-34, IP, HPR OIL 15W50, BP 2380 S 1,2,3,4,5,6 Capital Airways ARFF DESIGNATED CAT 6 (CAT 7 4 hr PN) 0915-0515Z‡ JASU Elect Start 10/15 Capital Airways PVT ADV Capital Airways Inc. 122.87 506-446-3588 Fax 506-446-3589 Mon-Fri 12-22Z‡ Sat-Sun 13-21Z‡ O/T 506-238-3653 PN call out chg. Air Canada Ground Handling 130.375 506-446-6133 MIL CON Irving Oil Commercial G.P 506-866-8143 RWY DATA Rwy 09(087°)/27(267°) 8005x200 ASPH Rwy 15(148°)/33(328°) 6000x150 ASPH RWY CERT Rwy 09 RVR 1200(1/4 sm)/Rwy 27 RVR 1200(1/4 sm) AGN V Rwy 15 RVR 1200(1/4 sm)/Rwy 33 RVR 1200(1/4 sm) AGN V TWY CERT Twy C AGN II Twy D AGN IIIB TWY Twy C uncontrolled NE of Twy D HELI DATA Rstd to max heli length of 49´ RCR Opr CRFI, win maint 0915-0400Z‡ PN for extended svc. PLR/PCN LIGHTING 09-AN(TE HI) P2, 27-AO(TE HI) P2, 15-AN(TE HI) P2, 33-AO(TE HI) P2 ARCAL-119.0 type K (when twr closed) CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE COMM RCO Saint John rdo 119.0 (RAAS) 0345-1045Z‡ ATIS 127.55 1045-0345Z‡ (O/T AWOS) GND 121.7 1045-0345Z‡ TWR 119.0 (E) 1045-0345Z‡ (emerg only 506-446-3420) MF Saint John rdo 119.0 0345-1045Z‡ 5NM 3500 ASL (CAR 602.98) PAL Moncton Ctr 124.3 135.5 270.8 VDF 119.0 1045-0345Z‡ NAV NDB VOR/DME DME ILS FC 326 (M) N45 55 02 W66 36 00 YFC 113.0 Ch 77 N45 53 41 W66 25 08 (52´) IDC 111.3 Ch 50 N45 51 47 W66 32 52 (86’) IDC 111.3 (Rwy 09) RVR PRO Dep Rwy 15 turn as soon as practicable after tkof to remain clear of CYR724. Transponder MODE C required within the Fredericton CZ. Pilots should refer to Canadian Airport Charts (CAC) to obtain details on established hot spots, prior to operating on maneuvering areas. CAC are available for free on the NAV CANADA website. VFR ARR/DEP ROUTES: See FREDERICTON VTPC - TRAINING AREAS CAUTION RESTRICTED AREAS: Extv live firing in CYR724, 725 4NM SE of aprt. AIRSPACE: Gagetown Class "E" CZ 3.5NM SE to 3500 ASL. FREDERICTON INTL NB (Cont’d) CYFC CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBVTPC-FREDERICTON - TRAINING AREAS FREDERICTON VFR TERMINAL PROCEDURES CHART - TRAINING AREAS CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBVTPC-FREDERICTON FREDERICTON VFR TERMINAL PROCEDURES CHART CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE LOCATION IDENT LAT/LONG BURTON BRIDGE VCBTB N45°51.90 W66°27.09 FRENCH LAKE VCFRL N45°46.00 W66°33.78 JEMSEG VCJMS N45°49.73 W66°07.00 MIDDLE ISLAND VCMDI N45°52.75 W66°24.97 LAKE GEORGE VCLKG N45°51.32' W66°55.57 PENNIAC VCPNC N46°02.00 W66°35.07 PRINCESS MARGARET BRIDGE VCRMB N45°57.42 W66°37.75 RIPPLES VCRPL N46°00.00 W66°13.00 RUSAGONIS VCRUS N45°48.00 W66°37.47 THE DAM VCDAM N45°57.38 W66°52.22 TRACY VCTRC N45°41.05 W66°41.08 VFR ROUTE PROCEDURES DEPARTURES: MACTAQUAC (NW): Outbound clear circuit, direct MACTAQUAC Dam enroute. Altitude: Climb to and maintain 2600 ft until clear of CZ. RIPPLES (ENE): Outbound clear circuit, direct RIPPLES enroute, maintain North of the VOR at all times. Altitude: Climb to and maintain 2600 ft until clear of CZ and then maintain 3000 ft until training area or at/abeam Grand Lake. PENNIAC DEPARTURE (N): Outbound clear circuit direct PENNIAC enroute. Altitude: Climb to and maintain 2600 ft until clear of CZ. JEMSEG (SE): Outbound: Follow RIPPLES DEPARTURE, then turn right (south) to JEMSEG enroute. Altitude: Climb to and maintain 3000 ft until at/abeam JEMSEG. TRACY (SW): Outbound clear circuit, direct TRACY enroute. Altitude: Climb to and maintain 2600 ft until clear of CZ. Departing aircraft must join the route as soon as practicable after departure (i.e. once clear of the circuit unless instructed by ATC to turn after departure), follow the routes as described and maintain 2,600 feet until they have departed the Fredericton CZ. ARRIVALS: HWY10 (ENE): Inbound direct RIPPLES, follow Hwy 10 until North of airport, then direct CYFC. Maintain North of VOR at all times. Altitude: If inbound from East, descend to 2500 ft before Grand Lake, then descend to and maintain 1600 ft prior to entering CZ. LAKE GEORGE (NW): Inbound direct Hwy 2 and Hwy 3 intersection, direct CYFC, maintain North of apch Rwy 09 at all times. Altitude: Descend to and maintain 1600 ft prior to entering CZ. PENNIAC (N): Inbound direct PENNIAC, direct CYFC. Altitude: Descend to and maintain 1600 ft prior to entering CZ. JEMSEG (SE): Inbound direct JEMSEG, direct RIPPLES, then follow HWY10 ARRIVAL. Altitude: Descend to 2500 ft at/abeam JEMSEG, then descend to and maintain 1600 ft prior to entering CZ. TRACY: Inbound direct TRACY, direct CYFC. Altitude: Descend to and maintain 1600 ft prior to entering CZ. Arriving aircraft must enter the Zone at 1,600', once inside CZ, descend at pilot's discretion, unless otherwise instructed, cleared or requested to maintain a specific altitude. FREDERICTON VFR TERMINAL PROCEDURES CHART (Cont’d) CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCYCX GAGETOWN NB (Heli) CYCX REF N45 50 16 W66 26 12 5SE 17°W (2015) UTC-4(3) Elev 166´ A5003 OPR DND 506-422-2394 CSN 319-432-2394 Mil PPR FLT PLN NOTAM FILE CYCX FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. MIL on site Ltd hrs WX Met brief for mil only. Lcl Met Section CSN 432-2613, JMC 1-800-WXMETEO (996-3836). (See COMM). METAR H24. TAF dur mil flt ops, issue times depending on mil requirements. PF B-1 C-2,3,4,5 SERVICES 403 Sqn svcg call "FIVE" 321.8 ltd hrs Mon-Fri exc hols FUEL F-34 OIL 156 ARFF CAT 2 MIL ADV 403 Sqn Ops call "ZERO" 321.8 ltd hrs Mon-Fri exc hols HELI DATA 150' x 150' Ctr of Pad N45 50.2 W66 26.2 Twy A 094°. Twy B 011°. LIGHTING DR RY(HI) Non std COMM MF PAL MIL 126.4 263.3 (E) Gagetown advsy avbl 11Z-0300Z‡ Mon-Fri O/T ltd hrs. Opr dates & hrs may vary without notice Moncton Ctr 124.3 135.5 270.8 46.8FM call sign Flt Following ltd hrs 49.9FM call sign Rng Ctl PRO Over flt of built up area 1.0NM W of heli proh below 1000 AGL Autorotation area lctd 0.5NM NNE of helipad. Circuits for helipad are left hand or opposite to Autorotation circuit when Autorotation area active. Autorotation area only active when Gagetown Advsy open. Due to close proximity to Fredericton Intl, Transit thru Burton Bridge for CYCX arr only, not auth for dep fr CYCX to CYFC. For transit to Rwy 27 at CYFC acft are to transit to the ammunition storage area (N45 51.05 W066 20.43). For transit to Rwy 09 at CYFC acft are to transit to the North Y (N45 49.05 W066 24.86). CAUTION HELI TRAFFIC: Extv heli activity around Gagetown day & night. RESTRICTED AREAS: Live firing in CYR 724 & CYR 725. Unless specifically authorized remain clear. JET TRAFFIC: Presence of mil jet acft in the range often unannounced. Unsked dly radiosonde balloon launches with an ascent rate of 1000 ft/min in the vic of Heli. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCK3 GRAND FALLS NB CCK3 REF N47 04 30 W67 41 06 2.6NE 18°W (2015) UTC-4(3) Elev 712´ A5002 A5003 LO8 OPR Grand Falls Avn 506-473-2566 Reg PF B-1,5 C-2,3,4,5,6 CUST AOE/CAN FLT PLN FIC ACC NOTAM FILE CYCL (bil) Québec 866-GOMÉTÉO or 866-WXBRIEF (Toll free within Canada) or 866-541-4105 (Toll free within Canada & USA). Flt Plns by Fax 418-871-4906 & include phone numbers where pilot can be reached prior to dep. (IFR only) Moncton 506-867-7177 or 866-480-8200. SERVICES FUEL OIL 100LL, JA All RWY DATA RCR Rwy 16/34 4600x75 ASPH/GRVL, centre 40´ asphalt first 3300´ Rwy 34. Thld 34 displ 720´. Opr Ltd win maint COMM DRCO ATF (bil) Québec rdo 126.7 (FISE) UNICOM ltd hrs O/T tfc 123.0 5NM 3700 ASL CAUTION Parachuting below 9500 ASL 5NM SSE. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCN2 GRAND MANAN NB CCN2 REF N44 42 48 W66 47 49 2NW 17°W (2013) UTC-4(3) Elev 244´ A5003 LO8 CAP OPR Grand Manan Aprt Comsn 506-662-7059 Reg PF B-1 C-2,4,5,6 CUST AOE/15 888-226-7277 1230-1600Z‡ Mon, Wed, Fri exc hols FLT PLN NOTAM FILE CYSJ FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. WX AUTO 506-662-7125 H24 (see COMM) RWY DATA Rwy 06(056°)/24(236°) 3009x75 asphalt Rwy 06 down 0.54% RCR Opr Ltd win maint PN LIGHTING 06-AS(TE ME) AP, 24-AR(TE ME) AP ARCAL-123.2 type K COMM ATF tfc 123.2 5NM 3200 ASL AUTO 122.175 CAUTION Deer in vic of rwy. Extensive bird activity in vic of aerodrome. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCS5 HAVELOCK NB CCS5 REF N45 59 11 W65 18 07 Adj SE 18°W (2014) UTC-4(3) Elev 425´ A5003 OPR Havelock Flying Club 506-534-2539/372-9744 Reg PF A-1 C-1 D-3,4,5,6 FLT PLN NOTAM FILE CYQM FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA Rwy 11/29 2860x235 turf Rwy 07/25 2090x260 turf RCR Opr Ltd win maint COMM ATF tfc 123.2 5NM 3400 ASL CAUTION High trees along both sides of rwys & at Thld 07 & 29. Marked P-line at Thld 25. Training areas around A/D, see Moncton VTPC - Training areas. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCE3 JUNIPER NB CCE3 REF N46 33 48 W67 10 06 2.5NE 18°W (2013) UTC-4(3) Elev 839´ A5003 LO8 RCAP OPR J.D. Irving Woodlands 506-632-7777 Reg PPR PF C-1 D-2,4,5 FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA Rwy 02(015°)/20(195°) 4499x53 ASPH RCR Opr Maint dur May-Oct. No win maint. COMM ATF tfc 123.2 5NM 3900 ASL CAUTION Water bombing tng over A/D. Hi trees on apch to Rwy 02. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCYCH MIRAMICHI NB CYCH REF N47 00 21 W65 27 25 1.6S 18°W (2017) UTC-4(3) Elev 110´ A5003 LO8 HI6 CAP OPR Miramichi Aprt Comsn 506-778-1031/9189 Cert PF A-1 (ltd hrs) C-2,3,4,5,6 FLT PLN NOTAM FILE CYCH FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. WX ALTIMETER/WIND 506-778-1031 11-23Z‡ (see COMM) WxCam SERVICES FUEL S SUP FL JASU Call out chg may be levied for one or more svcs 100LL, JA-1 1,2,4,5,6 D-ice PN 10/15 PN MILCON Miramichi Airport Commission (Irving Oil) 506-778-1031 RWY DATA Rwy 09(089°)/27(269°) 10006x150 asphalt RWY CERT Rwy 09/27 AGN V TWY Twy B avbl daytime only Twy B ltd win maint RCR Opr CRFI Ltd win maint, PN LIGHTING 09-AO(TE ME) P2, 27-AO(TE ME) P2 ARCAL-122.7 type K COMM ATF UNICOM (AU) 11-23Z‡ O/T tfc 122.7 5NM 3100 ASL PAL Moncton Ctr 123.7 NAV NDB F9 520 (L) N47 00 36 W65 28 03 Pvt CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE PRO Rgt hand circuits Rwy 09 (CAR 602.96). Do not overfly A/D during glider ops. CAUTION Glider operations on active runway and abandoned area N of Rwy 09/27 weekends May-Jun & Sep-Nov, vehicle & acft launching. Ctc glider ops 122.7 during activity. MIRAMICHI NB (Cont’d) CYCH CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCYQM MONCTON / GREATER MONCTON ROMÉO LEBLANC INTL NB CYQM REF N46 06 58 W64 40 43 4ENE 18°W (2013) UTC-4(3) Elev 232´ A5003 LO8 HI6 T2 CAP OC OPR Greater Moncton International Airport Authority Inc 506-856-5444 Cert PF A-1,2,6 C-3,4,5 CUST AOE/300 888-226-7277 12-04Z‡ FLT PLN NOTAM FILE CYQM FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. WX METAR H24 TAF H24, issue times: 00, 06, 12, 18Z CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE SERVICES Call out chg may be levied for one or more svcs. FUEL 100LL, JA-1 (FSII avbl) PN ASIG 506-857-9140 OIL All S 1,2 ARFF DESIGNATED CAT 6 (CAT 8 2 hr PN) 0945-0345Z (DT 0845-0245Z), O/T PN. SUP FL O & D-ice JASU (Hobart 1400 amp 30-40 volts), Elect Start 10/25, GTC/GTE-85 & NC-10A/A1/B/C PVT ADV Shell Aerocentre 122.15, ATS 131.75 Moncton Flight College 123.5 (Ltd hrs) Air Canada gnd hldg 130.37 506-857-1065 Skylink Express 131.37, ltd hangarage avbl MIL CON Irving Oil Commercial G.P 506-857-9140 RWY DATA Rwy 06(061°)/24(241°) 10,001x200 ASPH Rwy 11(106°)/29(286°) 8000x200 ASPH RWY CERT Rwy 06 RVR 1200(1/4sm)/Rwy 24 RVR 1200(1/4sm) AGN V Rwy 11 RVR 1200(1/4sm)/Rwy 29 RVR 1200(1/4sm) AGN V TWY CERT Twy: A, B, C, D AGN IV APRON Acft manoeuvring on apron VIII must maintain a listening watch & are to broadcast their movement intentions on Apron VIII Advisory 122.075. Itinerant acft wishing to use Apron VIII ctc Airport Security 506-856-5429 - 2 hr PN. Apron IV (Moncton Flight College) restricted to acft 8,000 lbs or less. RCR Opr 506-850-8430 10-19Z‡ Mon-Fri exc hol O/T 2 hrs PN, call out charge. CRFI/RSC, PLR/PCN LIGHTING 06-AN(TE HI), 24-AS(TE HI) P3, 11-AO(TE HI) P2, 29-AN(TE HI) COMM RCO ATIS APRON ADV GND TWR ARR DEP PAL London rdo 122.5 (FISE) 126.7 (bcst) 128.65 506-867-7224 Apron VIII 122.075 121.8 275.8 120.8 236.6 (E) (emerg only 506-867-7220) 124.4 124.4 124.4 127.125 132.2 NAV NDB VOR/DME ILS QM 224 (M) N46 06 38 W64 34 55 RIVERVIEW ZQM 304 (L) N46 02 19 W64 46 59 LEWISVILLE ZMN 366 (L) N46 06 16 W64 47 30 YQM 117.3 Ch 120 N46 11 20 W64 34 15 (172´) IQM 109.3 (Rwy 29) RVR; IFG 109.7 (Rwy 06) RVR PRO De-icing apron VIII - Prior to pushback, broadcast intentions & monitor all movements on Apron Advisory 122.075. Proceed to de-icing pad. Pilots should refer to Canadian Airport Charts (CAC) to obtain details on established hot spots, prior to operating on maneuvering areas. CAC are available for free on the NAV CANADA website. CAUTION Para activity from 12,500 ASL, 6NM NW. Training areas around CZ, see Moncton VTPC - Training areas. MONCTON / GREATER MONCTON ROMÉO LEBLANC INTL NB (Cont’d) CYQM CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCG4 MONCTON / McEWEN NB CCG4 REF N46 09 14 W64 46 07 Adj 3N 18°W (2015) UTC-4(3) Elev 214´ A5003 OPR Maritime Airways 506-389-9088 Reg PPR PF A-1 C-2,3,4,5,6 FLT PLN NOTAM FILE CYQM FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA Rwy 08/26 3000x80 asphalt/grass, centre 35´ asphalt Thld 08 displ 395´. RCR Opr Ltd win maint LIGHTING 08-(TE LO), 26-(TE LO) COMM ATF UNICOM ltd hrs O/T tfc 122.8 5NM 3200 ASL excluding that portion in the Moncton CZ. PRO Rgt hand circuit Rwy 26 (CAR 602.96). IFR dep clnc ctc Moncton gnd 121.8 CAUTION Parajump activity to 12,500 ASL. Ctc Moncton twr for current info. Grass area of rwy soft when wet. Training areas around A/D, see Moncton VTPC - Training areas. Blasting ops aprx 4NM WNW of A/D Mon-Fri (N46 09 42 W64 52 38 to N46 10 00 W64 51 14 to N46 10 08 W64 51 18 to N46 10 20 W64 51 49 to N46 09 53 W64 52 42 to N46 09 42 W64 52 38) sfc up to 820 ASL. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCDB5 MONCTON / SALISBURY NB (Heli) CDB5 REF N46 02 58 W65 03 45 1.5NW 18°W (2015) UTC-4(3) Elev 230´ A5003 OPR Irving Oil Ltd 506-202-1121 Reg PF B-1,2 D-3,4,5,6 FLT PLN NOTAM FILE CYQM FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. HELI DATA RCR 80´x 80´ Gravel Opr No win maint COMM ATF tfc 123.2 5NM 3200 ASL PRO Arr/dep btwn 098° & 343° fr heli. CAUTION Training areas around heliport, see Moncton VTPC - Training areas. Unmarked fur farm 2NM S of helipad, within the published arr/dep path. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBMISC-MONCTON CENTRE MONCTON CENTRE (emerg only 506-867-7173) CZQM 124.4 124.4 127.125 127.125 132.2 132.2 132.7 133.875 (FL 290 & above) 294.5 Caledonia Mtn 132.5 Charlo 134.25 Charlottetown 135.65 Churchill Falls 132.95 (FL 290 & above) Fredericton 124.3 135.5 270.8 Grindstone 132.8 (FL 290 & above) 134.35 Halifax 133.95 (FL 290 & above) 135.3 Miramichi 123.7 Natashquan 118.875 124.975 (FL 290 & above) 132.525 Saint John 124.3 135.5 270.8 Sept-Îles 126.325 133.35 368.5 (FL 290 & above) Stephenville 133.55 135.775 (FL 290 & above) Sydney 118.6 125.25 132.75 133.3 133.7 (FL 290 & above) 266.3 Trenton 135.3 135.65 Yarmouth 123.9 128.375 132.975 135.2 368.5 CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBVTPC-MONCTON - TRAINING AREA EAST MONCTON VFR TERMINAL PROCEDURES CHART - TRAINING AREAS MONCTON FLIGHT COLLEGE - EAST PORTION CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBVTPC-MONCTON - TRAINING AREA WEST MONCTON VFR TERMINAL PROCEDURES CHART - TRAINING AREAS MONCTON FLIGHT COLLEGE - WEST PORTION CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBVTPC-MONCTON MONCTON VFR TERMINAL PROCEDURES CHART VFR FLIGHT PROCEDURES ARRIVALS - Join arrival route as close as possible to starting point and fly the assigned route as per the diagram. - MAINTAIN 2000’ until advised by tower. - All routes end approximately 2NM from airport, join circuit as per tower instructions. DEPARTURES - Join departure route as soon as possible after departure and fly the assigned route as per the diagram. - MAINTAIN 1500’ until advised or leaving the zone. - All routes start approximately 2NM from airport. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCDA4 POKEMOUCHE NB CDA4 REF N47 42 58 W64 52 54 6S 19°W (2012) UTC-4(3) Elev 69’ A5003 A5010 LO8 RCAP OPR Aéroport de la Péninsule (1985) Inc 506-727-4215 Reg Ldg fees PF B-1 C-2,3,4,5 FLT PLN FIC ACC NOTAM FILE CYCL (bil) Québec 866-GOMÉTÉO or 866-WXBRIEF (Toll free within Canada) or 866-541-4105 (Toll free within Canada & USA). Flt Plns by Fax 418-871-4906 & include phone numbers where pilot can be reached prior to dep. (IFR only) Moncton 506-867-7177 or 866-480-8200. SERVICES FUEL OIL S 100LL Ltd hrs 506-727-4215 80, 15W50 4,5,6 RWY DATA RCR Rwy 12(124°)/30(304°) 3400x75 ASPH Rwy 12 down 0.41% Opr Ltd win maint LIGHTING 12-(TE ME), 30-AS(TE ME) AP ARCAL-122.350 key mic 3 times within 5 sec for 15 min dur. Key mic 5 times to turn off RIL. COMM RCO ATF (bil) Québec rdo (Bathurst) 123.475 (FISE) 126.7 (bcst) (may not be receivable on the ground) UNICOM ltd hrs O/T tfc 122.350 5NM 3100 ASL CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCSN6 SAINT JOHN (SAINT JOHN REGIONAL HOSPITAL) NB (Heli) CSN6 REF N45 18 08 W66 05 17 1.5N 18°W (2013) UTC-4(3) Elev 246´ A5003 OPR Saint John Regional Hospital Atlantic Health Sciences Corp 506-648-6614 Cert PPR FLT PLN NOTAM FILE CYSJ FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. HELI DATA FATO/TLOF 92´ x 92´ ASPH Safety Area 122’ x 122’ ASPH/GRASS Max heli overall length 61' Rstd to medevac & govt use RCR Opr Ltd win maint LIGHTING RF(FL) COMM RCO London rdo 123.475 (FISE) 126.7 (bcst) ATF tfc 123.2 5NM 3300 ASL PRO Arr/dep 318° and 224° fr heli, slope 8% (H3) CAUTION Lgtd smokestack 377 ASL (126 AGL) 490´ SE fr heli. Lgtd smokestack 405 ASL (205 AGL) aprx 440´ SE fr heli. Lgtd windsock 149' NE fr heli. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBFSS - ST-JOHN SAINT JOHN FSS -RCO Fredericton 119.0 (RAAS) 0345-1045Z‡ (N45 52 W66 32) CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBVTPC-SAINT JOHN - TRAINING AREAS SAINT JOHN VFR TERMINAL PROCEDURES CHART - TRAINING AREAS CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCYSJ SAINT JOHN NB CYSJ REF N45 18 57 W65 53 24 8ENE 18°W (2014) UTC-4(3) Elev 357´ A5003 LO8 HI6 CAP OPR Saint John Airport Inc 506-638-5555 Cert PF A-1,2,3,6,7 09-04Z‡ C-4,5 CUST AOE/120 (140 with staged off-loading) 888-226-7277 12-04Z‡ FLT PLN NOTAM FILE CYSJ FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. WX METAR H24 TAF H24, issue times: 00, 06, 12, 18Z SERVICES Call out chg may be levied for one or more svcs FUEL 100LL H24 self-serve, JA (FSII avbl) 12-21Z‡ Mon-Fri, JA-1 (FSII avbl) 08-24Z‡ OIL All S 1(ltd, for lgt acft),2,4,5,6 ARFF DESIGNATED CAT 6 0900-0330Z‡, O/T call out chg. JASU CE8, CA2 PVT ADV Atlantic Flt Centre 123.3 12-21Z‡ Mon-Fri 506-634-5565 O/T 506-650-8402, exc hols; Air Canada Ground Handling 130.37 506-632-1524 MIL CON ASIG Canada (Irving Oil) 506-653-7409 CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE RWY DATA Rwy 05(049°)/23(229°) 7201x148 ASPH Thlds 05 & 23 displ 197’ Rwy 14(138°)/32(318°) 5100x148 ASPH Rwy 14 down 0.84% Rwy 14/32 avbl as twy dur night when Rwy 05/23 RVR 1200(1/4sm) down to 600(1/8sm) RESA: All Rwys 492’ RWY CERT Rwy 05 RVR 600(1/8sm)/Rwy 23 RVR 600(1/8sm) AGN IV Rwy 14 RVR 1200(1/4sm)/Rwy 32 RVR 1200(1/4sm) AGN IV TWY CERT Twy I AGN IIIB TWY Twy I Pvt RCR Opr CRFI and win maint avbl ltd hrs. PLR/PCN LIGHTING 05-AN(TE HI CL), 23-AN(TE HI CL), 14-AS(TE ME) P2, 32-AO(TE ME) P2 COMM RADIO 118.5 236.6 (E) (emerg only 506-646-7225) RCO London rdo 123.475 (FISE) 126.7 (bcst) MF rdo 118.5 5NM 3400 ASL (CAR 602.98) PAL Moncton Ctr 124.3 135.5 270.8 NAV NDB SJ 212 (M) N45 23 30 W65 49 08 ALPINE ZST 397 (L) N45 13 40 W65 57 30 VOR/DME YSJ 113.5 Ch 82 N45 24 26 W65 52 15 (494´) ILS ISJ 110.5 (Rwy 23) RVR; IDM 108.3 (Rwy 05) RVR PRO Pursuant to CAR 602.96, in vis conds blw 1/8sm with an RVR of 600 or greater, an IFR clnc must be obtained prior to taxiing for dep and acft are not auth to taxi when another acft is on the maneuvering area, or on apch to any rwy. Ctc CYSJ FSS for tfc status. Pilots should refer to Canadian Airport Charts (CAC) to obtain details on established hot spots, prior to operating on maneuvering areas. CAC are available for free on the NAV CANADA website. Low Visibility Procedure: See CAP SAINT JOHN NB (Cont’d) CYSJ CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCF9 SCOTTSFIELD AIRPARK NB CCF9 REF N45 57 37 W67 05 43 17°W (2015) UTC-4(3) Elev 600´ A5003 OPR Ernie McLean 506-575-1910/8615 506-260-2932 Reg PF B-1 C-2,3 D-3,4,5 FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. SERVICES OIL S 15W50 4,5 RWY DATA RCR Rwy 05/23 2500x100 turf Opr No win maint First 400´ each rwy soft in spring/fall COM ATF tfc 123.2 5NM 3600 ASL CAUTION Weyman Airpark aprx 12NM E, ATF 123.2. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCM3 SEVOGLE NB CCM3 REF N47 11 W66 09 18°W (2015) UTC-4(3) Elev 1350´ A5003 OPR New Brunswick Dept of Natural Resources 506-778-6672 (summer) 506-453-2530 (winter) Reg PN FLT PLN FIC ACC NOTAM FILE CYCL (bil) Québec 866-WXBRIEF or 866-GOMÉTÉO (Toll free within Canada) or 866-541-4105 (Toll free within Canada & USA). Flt Plns by Fax 418-871-4906 & include phone numbers where pilot can be reached prior to dep. (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA RCR Rwy 16/34 3100x60 treated gravel Opr No win maint COMM ATF tfc 123.2 5NM 4400 ASL CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCSB5 SHEDIAC BRIDGE NB CSB5 REF N46 15 17 W64 34 36 1S 18°W (2015) UTC-4(3) Elev 25´ A5003 OPR Maurice R. Hébert 506-866-7222 Reg PPR PF C-1,2,3,4,5 D-6 FLT PLN NOTAM FILE CYQM FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA RCR Rwy 09/27 2750x75 gravel Opr No win maint COMM ATF tfc 123.2 5NM 3100 ASL CAUTION Rwy may be soft when wet. Unmarked power lines on apch to Rwy 27. Training areas around A/D, see Moncton VTPC - Training areas. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCYSL ST. LEONARD NB CYSL REF N47 09 26 W67 50 11 4SE 18°W (2012) UTC-4(3) Elev 794´ A5002 A5003 LO8 CAP OPR JD Irving Ltd 506-632-7777 Reg PPR PF A-1 C-2,3,4,5,6 FLT PLN NOTAM FILE CYCL FIC (bil) Québec 866-WXBRIEF or 866-GOMÉTÉO (Toll free within Canada) or 866-541-4105 (Toll free within Canada & USA). Flt Plns by Fax 418-871-4906 & include phone numbers where pilot can be reached prior to dep. ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA Rwy 18(174°)/36(354°) 4021x100 asphalt Rwy 36 down 0.32% RCR Opr CRFI, Ltd win maint. PLR/PCN LIGHTING 18-AO(TE ME) AP, 36-AS(TE ME) AP ARCAL-122.7 type K COMM DRCO (bil) Québec rdo 126.7 (FISE) ATF tfc 122.7 5NM 3800 ASL CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCS3 ST. STEPHEN NB CCS3 REF N45 12 25 W67 14 59 1NE 17°W (2016) UTC-4(3) Elev 99´ A5003 LO8 CAP OPR Town 506-466-7717 Reg PF B-1 C-2,3,4,5,6 CUST AOE/15 888-226-7277 FLT PLN NOTAM FILE CYSJ FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. WX WxCam SERVICES 12-21Z‡ 506-466-8853 O/T 506-466-1223 or 506-422-1903 PN FUEL 100LL OIL All RWY DATA Rwy 13(133°)/31(313°) 2963x75 ASPH Rwy 13 down 0.37% RCR Opr Ltd win maint. LIGHTING 13-(LO), 31-(LO) ARCAL-122.8 type J COMM ATF UNICOM ltd hrs O/T tfc 122.8 5NM 3100 ASL PRO Rgt hand circuits Rwy 31 (CAR 602.96) CAUTION Obst twr 320 AGL 1.5NM SE. Parajumps May-Oct max alt 10,000 ASL. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCY3 SUSSEX NB CCY3 REF N45 41 11 W65 32 31 3SW 18°W (2015) UTC-4(3) Elev 467' A5003 OPR Ross Keirstead 506-433-3554 Reg PF C-1,2,3,4,5,6 FLT PLN NOTAM FILE CYSJ FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA Rwy 04/22 3200x60 treated gravel (first 600´ Rwy 04 treated gravel/grass) RCR No win maint COMM ATF tfc 123.2 5NM 3400 ASL CAUTION Ocsl wildlife on rwy. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCH2 UPPER KENT NB CCH2 REF N46 35 15 W67 43 09 1.1NNW 18°W (2011) UTC-4(3) Elev 246' A5002 A5003 OPR Bruce Lockhart 506-278-5161 Reg PF C-2 D-5 FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) RWY DATA Rwy 01(014°)/19(194°) 1400x70 turf RCR Opr No win maint COMM ATF tfc 122.8 5NM 3300 ASL CAUTION Lgtd towers 200 AGL aprx 1NM NW and aprx 1NM SW of A/D. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCG3 WEYMAN AIRPARK NB CCG3 REF N46 02 15 W66 51 32 17°W (2015) UTC-4(3) Elev 140´ A5003 OPR David Bradley 506-450-4087 Reg PPR PF B-1 C-2 D-3,4,5,6 FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. RWY DATA Rwy 05/23 3000x80 sand/gravel/chip seal RCR Opr No win maint COMM ATF tfc 123.2 5NM 3100 ASL CAUTION Glider activity Apr 15-Dec 15. Rwy may be soft during thaw. Scottfield Airpark aprx 12NM W, ATF 123.2. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCSN4 WOODSTOCK / SNOKIST NB (Heli) CSN4 REF N46 12 10 W67 39 34 3.9NNW 17°W (2019) UTC-4(3) Elev 481' A5002 A5003 OPR Foxco Ltd. 506-328-6524 or 506-323-0073 Reg PPR PF B-1 C-2,3,5,6 FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) SERVICES S 6,7 HELI DATA FATO 45’ dia CONC TLOF 20’x20’ CONC PAD 20’x20’ CONC Safety Area 90’x140’ ASPH Max heli overall length 43' LIGHTING RF(FH) ARCAL-121.7 type J CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE NBCCD3 WOODSTOCK NB CCD3 REF N46 09 W67 33 1.1E 17°W (2015) UTC-4(3) Elev 481´ A5002 A5003 OPR Town 506-325-4600/8526 Reg PF B-1 C-2,3,4,5,6 FLT PLN NOTAM FILE CYFC FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Moncton 506-867-7177 or 866-480-8200. SERVICES S 1,4,5 RWY DATA Rwy 13/31 3000x75 chipseal/turf First 1000´ Rwy 13 turf remaining 2000´ chipseal RCR Opr No win maint. Turf may be soft in spring. COMM ATF tfc 123.2 5NM 3500 ASL CAUTION Extensive ultra-light activity with 500 AGL circuits. Wildlife may be present. CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 AERODROME / FACILITY DIRECTORY NEW BRUNSWICK SAMPLE CANADA FLIGHT SUPPLEMENT CAUTION: THE INFORMATION IN THIS PUBLICATION MAY BE SUPERSEDED BY NOTAM OR AIP SUPPLEMENT AIP Canada (ICAO) Part 3 - Aerodromes (AD) Department of National Defence Flip GPH 205 ATLANTIC TERMINAL AND ENROUTE DATA CFS DIGITAL EDITION DIGITAL EDITION EFFECTIVE 0901Z 31 December 2020 TO 0901Z 25 February 2021 SAMPLE CANADA FLIGHT SUPPLEMENT CAUTION: THE INFORMATION IN THIS PUBLICATION MAY BE SUPERSEDED BY NOTAM OR AIP SUPPLEMENT AIP Canada (ICAO) Part 3 - Aerodromes (AD) Department of National Defence Flip GPH 205 NEWFOUNDLAND AND LABRADOR TERMINAL AND ENROUTE DATA CFS DIGITAL EDITION DIGITAL EDITION EFFECTIVE 0901Z 31 December 2020 TO 0901Z 25 February 2021 SAMPLE Published by NAV CANADA in accordance with ICAO Annexes 4 and 15 of the Convention on International Civil Aviation Cartography and Printing: NAV CANADA Source of Canadian Civil Aeronautical Data: © 2020 NAV CANADA All rights reserved Source of Canadian Military Aeronautical Data: Her Majesty the Queen in Right of Canada Department of National Defence SAMPLE NLCCV4 BELL ISLAND NL CCV4 REF N47 38 06 W52 58 49 Adj 19°W (2014) UTC-3 1/2(2 1/2) Elev 191´ A5012 LO8 CAP OPR Govt of Newfoundland & Labrador 709-729-2382 Reg PF C-1,2,3,4,5 FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 08(076°)/26(256°) 2296x75 ASPH RCR Dept of Highways 709-488-3842 Ltd win maint PN COMM ATF tfc 123.2 5NM 3200 ASL CAUTION Ocsl rdo ctl acft and motorsport activity peak periods wknds May-Sep. Possible wildlife on rwy. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCE4 BLACK TICKLE NL CCE4 REF N53 28 12 W55 47 15 1NW 22°W (2013) UTC-4(3) Elev 52´ A5020 LO7 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-1,2,4,5 FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 14(143°)/32(323°) 2503x75 gravel Rwy 32 down 1% RWY CERT Rwy 14/32 AGN II RCR Opr 709-471-8898/8907 Ltd win maint, ctc opr. LIGHTING 14-AS(TE ME) AP, 32-AS(TE ME) AP ARCAL-122.8 type K, key mic 7 times for RILS. COMM ATF tfc 122.8 5NM 3100 ASL See PRO section NAV NDB 1E 349 (M) N53 28 02 W55 47 19 Pvt Unmonitored PRO A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYCA CARTWRIGHT NL CYCA REF N53 40 57 W57 02 31 1.5SW 22°W (2013) UTC-4(3) Elev 42´ A5020 LO7 HI1 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-1,2,3,4,5 FLT PLN NOTAM FILE CYCA FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX METAR AUTO H24 (see COMM) WxCam TAF H24, issue times: 02, 08, 14, 20Z. RWY DATA Rwy 08(078°)/26(258°) 3937x75 gravel RWY CERT Rwy 08/26 AGN II RCR Opr 709-938-7323/7212 Ltd win maint LIGHTING 08-AS(TE ME) AP, 26-AS(TE ME) AP ARCAL-122.8 type K key mic 7 times for RILS. COMM ATF tfc 122.8 5NM 3000 ASL See PRO section AWOS 128.75 NAV NDB CA 281 (M) N53 42 33 W57 01 16 PRO Rgt hand circuits Rwy 26 (CAR 602.96). A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCH4 CHARLOTTETOWN NL CCH4 REF N52 45 57 W56 06 45 Adj S 22°W (2013) UTC-3 1/2(2 1/2) Elev 210´ A5020 LO7 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF D-1,2,4,5 FLT PLN NOTAM FILE CYAY FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 09(092°)/27(272°) 2502x75 gravel Rwy 27 down 1.48% RWY CERT Rwy 09/27 AGN II RCR Opr 709-949-0268/0226 Ltd win maint, ctc opr. LIGHTING 09-AS(TE ME) AV 4°, 27-AS(TE ME) AV 4° ARCAL-122.8 type K key mic 7 times for RILS. COMM ATF tfc 122.8 5NM 3200 ASL See PRO section NAV NDB 1D 346 (M) N52 46 31 W56 07 33 Pvt Unmonitored PRO Rgt hand circuits Rwy 27 (CAR 602.96). A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCZUM CHURCHILL FALLS NL CZUM REF N53 33 45 W64 06 21 4NW 22°W (2013) UTC-4(3) Elev 1442´ A5020 LO7 HI1 CAP OPR Churchill Falls (Labrador) Corp 709-925-3405 Ldg fees Cert PF A-1 C-2,4,5 FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX METAR AUTO H24 (see COMM) WxCam TAF H24, issue times: 02, 08, 14, 20Z. SERVICES PN for svcs. Ramp and other fac svc fees may apply. FUEL JA-1 12-16Z‡, 17-21Z‡ Mon-Fri; Sat, Sun & hols call 709-925-8280. Call out chg and fuel hook up fee will be levied. S 5 RWY DATA Rwy 13(126°)/31(306°) 5500x148 ASPH RWY CERT Rwy 13 RVR 1200(1/4sm)/Rwy 31 RVR 1200(1/4sm) AGN IV RCR Opr 1230-1600Z‡, 1700-2030Z‡ Mon-Fri exc hols O/T 3 hrs PN, call out chg may apply. Ltd win maint, PLR/PCN LIGHTING 13-AO(TE ME) P2, 31-AO(TE ME) P2 ARCAL-123.5 type K COMM RCO London rdo 123.25 (FISE) 126.7 (bcst) ATF tfc 123.5 5NM 4400 ASL PAL Gander Ctr 126.025 AWOS 118.95 NAV NDB UM 233 (M) N53 35 26 W64 14 08 CAUTION Migratory bird activity in vic of aprt spring and win. Ocsl standing water on rwy. Extv heli activity in vic. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCZ3 CLARENVILLE NL CCZ3 REF N48 16 29 W53 55 26 7.5N 19°W (2013) UTC-3 1/2(2 1/2) Elev 203´ A5012 LO8 CAP OPR Govt of Newfoundland & Labrador 709-466-4132 or 709-256-1048 Reg PF D-1,2,3,4,5,6 FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 08(077°)/26(257°) 3938x75 asphalt Rwy 26 down 0.63% RCR Dept of Highways 709-466-4120 Ltd win maint PN LIGHTING 08-AS(TE ME), 26-AS(TE ME) ARCAL-122.8 type K key mic 7 times for RILS. COMM ATF tfc 123.2 5NM 3200 ASL CAUTION Rwy maybe clsd wknds fr May to Nov by NOTAM. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLFSS - DEER LAKE DEER LAKE FSS - RCO St. Anthony 122.3 (RAAS) (N51 23 31 W56 04 59) AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYDF DEER LAKE NL CYDF REF N49 12 33 W57 23 40 3NNE 20°W (2013) UTC-3 1/2(2 1/2) Elev 72´ A5011 A5012 LO8 HI6 CAP OPR Deer Lake Regional Airport Authority Inc. 709-635-3601 Cert PF A-1,2,3,6 C-4,5 CUST AOE/120 (250 with staged off-loading) 888-226-7277 1830-0230Z‡ Mon-Fri, Feb 1-May 30; 1130-1930Z‡ Mon-Fri, Jun 22-Sep 30; AOE/15 H24 FLT PLN NOTAM FILE CYDF FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX METAR H24. TAF H24, issue times: 02, 08, 14, 20Z. SERVICES FUEL 100LL, JA-1 OIL All ARFF DESIGNATED CAT 6 (CAT 7 30 min PN) 0830-0430Z‡, O/T call out chg. PVT ADV Nalair 122.85 709-635-3574 Fax 709-635-3901 Woodward Aviation 709-635-3776 MIL CON Woodward's Oil Limited 709-635-3776 AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE RWY DATA Rwy 07(066°)/25(246°) 8005x150 asphalt Rwy 07 up 0.35% RWY CERT Rwy 07 RVR 1200(1/4sm)/Rwy 25 RVR 1200(1/4sm) AGN IV HELI DATA Two 50´ dia pads. RCR Opr CRFI 0830-0430Z‡ PN for extended svc PLR/PCN LIGHTING 07-AN (TE HI) P2, 25-AN (TE HI) COMM RADIO 122.2 239.6 (E) (emerg only 709-635-2848) RCO London rdo 123.375 (FISE) 126.7 (bcst) MF rdo 122.2 5NM 3100 ASL (CAR 602.98) PAL Gander Ctr 134.6 VDF 122.2 NAV VOR/DME YDF 113.3 Ch 80 N49 13 57 W57 12 48 (450') DME IDF 108.3 Ch 20 N49 12 55 W57 23 14 (96') ILS IDF 108.3 (Rwy 25-07) CAUTION Water tower 1NM N of thld Rwy 25, 225 ASL. DEER LAKE NL (Cont’d) CYDF AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCP2 EXPLOITS VALLEY (BOTWOOD) NL CCP2 REF N49 03 22 W55 26 52 6WSW 20°W (2013) UTC-31/2(21/2) Elev 328’ A5011 A5012 LO8 CAP OPR Govt of Newfoundland & Labrador 709-292-4326 or 709-256-1048 Reg PF D-1,2,3,4,5,6 FLT PLN FIC NOTAM FILE CYYT London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 06(063°)/24(243°) 4007x75 asphalt Rwy 06 down 0.3% RCR Opr Ltd win maint PN LIGHTING 06-AS(TE ME), 24-AS(TE ME) ARCAL-122.8 type K key mic 7 times for RILS. COMM ATF tfc 123.2 5NM 3400 ASL CAUTION Multiple cracks and heaves on the apron and rwy. Pilots should exercise caution when oprg at this A/D. Wildlife on or in vic of rwy. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCDY3 FOGO NL CDY3 REF N49 39 27 W54 14 15 4S 20°W (2013) UTC-3 1/2 (21/2) Elev 97´ A5012 LO8 CAP OPR Govt of Newfoundland & Labrador 709-292-4326 or 709-256-1048 Reg PF C-1,2,3,4,5 FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 10(103°)/28(283°) 3000x75 asphalt RCR Opr Ltd win maint PN LIGHTING 10-AS(TE ME), 28-AS(TE ME) ARCAL-122.8 type K key mic 7 times for RILS. COMM ATF tfc 123.2 5NM 3100 ASL NAV NDB 7C 237 (L) N49 39 42 W54 14 43 Pvt Unmonitored CAUTION Wildlife on or in vic of rwy. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCGH2 GANDER (JAMES PATON MEM REGIONAL HEALTH CENTRE) NL (Heli) CGH2 REF N48 57 19 W54 37 38 Adj W 19°W (2014) UTC-3½(2½) Elev 432' A5012 OPR James Paton Mem Regional Health Centre 709-256-5552/2500 Cert PN PF A-1,2,3,4 C-5,6 FLT PLN NOTAM FILE CYQX FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. HELI DATA FATO/TLOF 79' x 79' ASPH Safety Area 105’ x 105’ ASPH Max heli overall length 52.5’ RCR Opr Ltd win maint COMM TWR Gander 118.1 at Gander Intl A/D 2.4NM SE PRO Arr/dep btwn 151°-243° fr heli, slope 8% (H3). Portion of arr/dep path overlies golf course. Verify that sufficient suitable and reachable emergency landing areas are available and not occupied by persons on the ground prior to use of arr/dep path. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLMISC-GANDER CENTRE GANDER CENTRE (emerg only 709-651-5324) CZQX 124.175 125.9 (FL290 & above) 128.5 128.5 132.1 132.1 (extended range) (FL280 & below) 132.6 133.9 (FL290 & above) 289.4 289.4 (FL280 & below) Allen's Island 124.05 (FL 290 & above) Brevoort 124.825 128.075 (FL290 & above) (132.025 132.025 (FL280 & below) (Clnc Del 2330-0730Z‡) O/T Montreal Centre) Cape Dyer 132.55 (FL290 & above) Churchill Falls 121.375 (FL290 & above) 126.025 126.025 (FL280 & below) 128.7 (FL290 & above) 12-20Z‡ (128.7 128.7 (FL280 & below) Clnc Del 2330-0730Z‡) Deer Lake 134.6 134.6 (FL280 & below) Goose Bay 120.4 120.4 (FL280 & below) 125.75 127.675 132.4 133.425 (FL290 & above) 294.5 294.5 (FL280 & below) Hibernia 118.25 118.25 (FL280 & below) Hopedale 120.55 125.375 128.325 132.65 (FL290 & above) 135.4 135.4 (FL280 & below) Kuujjuaq 134.2 134.2 (FL280 & below) Clnc Del 2330-0730‡ O/T Montreal Centre Natashquan 135.45 (FL180 to FL280 outside Clnc Del hrs) (135.45 135.45 (FL280 & below) Clnc Del 2330-0730Z‡) Saglek 119.625 123.75 128.475 135.325 (FL290 & above) St. Anthony 119.85 124.725 126.45 128.6 134.3 (FL290 & above) 133.0 133.0 371.9 371.9 (FL280 and below) St. John's (NL) 125.075 128.175 132.05 132.475 (FL290 & above) 133.15 133.15 (FL280 & below) 134.7 (FL290 & above) 135.35 135.35 227.3 227.3 (FL280 & below) St. Pierre (Allen's Is) (128.45 128.45 (FL280 & below) Clnc Del 2330-0730Z‡) 134.9 134.9 (FL280 & below) Stephenville 120.325 120.325 (FL280 & below) (135.05 135.05 (FL280 & below) Clnc Del 2330-0730Z‡) Sydney 119.425 119.425 (FL280 & below) Clnc Del 2330-0730Z‡ Wabush 119.7 134.0 (FL290 & above) AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYQX GANDER INTL NL CYQX REF N48 56 13 W54 34 05 Adj SE 20°W (2013) UTC-31/2 (21/2) Elev 496´ A5012 LO8 HI6 T2 CAP OC OPR Gander International Airport Authority Inc 709-256-6666 Cert DND CSN 319-622-3342 PF A-1,2,3,6 C-4,5 AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE CUST AOE 888-226-7277 FLT PLN NOTAM FILE CYQX FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX METAR H24. TAF H24, issue times: 00, 06, 12, 18Z. SERVICES Mil acft hg space very ltd, PPR for hg space. For emerg, space can be made avbl, ctc Gander Wg Ops CSN 86-622-1213 or 709-256-1703 Ext 1213 1130-2000Z‡ Mon-Fri exc hols. O/T ctc Wg Duty Officer 709-235-0429. Cdn mil tran svcg not avbl 103 Sqn, ctc Allied Aviation 129.10, comm 709-256-3041. FUEL F-34, JA-1, JB, HPR OIL All S 1,2 ARFF PARTICIPATING CAT 5 (CAT 6, CAT 7 30 MIN PN) (CAT 8 1 hr PN) 709-256-6666 SUP FL ADI, D & A-ice JASU 10/15, CE13, 14, 15, CA1 MIL ADV Outcast Ops 128.85 252.8 1030-1900Z‡ Mon-Fri exc hols 709-256-1703 Ext 1342 PVT ADV Allied Avn 129.1; Woodward Avn 122.7 709-256-4414; Gander Avn 122.55; Irving Avn Svcs 122.9; GFT Avn Svcs 123.35 709-256-7484/709-424-5074 MIL CON Woodward's Oil 709-256-4414 RWY DATA Rwy 03(030°)/21(210°) 10,200x200 asphalt Rwy 13(128°)/31(308°) 8900x200 asphalt Rwy 31 up 0.33% RESA: 21 295’ RWY CERT Rwy 03 RVR 1200(1/4sm)/Rwy 21 RVR 1200(1/4sm) AGN VI Rwy 13 RVR 1200(1/4sm)/Rwy 31 RVR 1200(1/4sm) AGN VI TWY CERT Twy C AGN IIIB RCR Opr CRFI, PLR/PCN. TDT800 LIGHTING 03-AN(TE HI), 13-AN(TE HI), 21-AO(TE HI) P3, 31-AO(TE HI) P3 COMM RCO ATIS GND TWR ARR DEP MIL INTL AIR London rdo 123.475 (FISE) 126.7 (bcst) 124.8 121.9 275.8 118.1 236.6 (E) (emerg only 709-651-5329) 128.5 132.1 128.5 132.1 Outcast Ops 128.85 252.8 For a description of HF Aeromobile Operations in the NAT & associated hrs of operation for Gander IFSS, refer to the AIP GEN Section 3.4 Communication Services. NAV NDB VOR/DME DME ILS QX 280 (M) N48 57 52 W54 40 13 YQX 112.7 Ch 74 N48 53 59 W54 32 06 (612´) IQX 109.5 Ch 32 N48 57 02 W54 33 37 (461´) IQX 109.5 (Rwy 03) RVR; IGN 109.9 (Rwy 13) RVR PRO Parachute ops on the field require 30 minutes PN thru fire hall 709-256-6674. ATS REQUIREMENTS: All acft dep fr inside CZ must ctc TWR on freq 118.1 or 709-651-5329 prior to tkof. Pilots should refer to Canadian Airport Charts (CAC) to obtain details on established hot spots, prior to operating on maneuvering areas. CAC are available for free on the NAV CANADA website. CAUTION Snow banks N and S of Apron III Nov-Apr. Recreational remote ctl acft operating area 3.1NM S of A/D, 770 ASL and blw. GANDER INTL NL (Cont’d) CYQX AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLMISC -GANDER RADIO GANDER RADIO-RCO Cambridge Bay Intl Air 2971 4675 8891 11279 Nat 'D' (SELCAL) Iqaluit Intl Air 2971 4675 8891 11279 Nat 'D' (SELCAL) Brevoort 124.825 (shared with Gander ACC FL290 & above) Frederiksdal, Greenland Intl Air 118.42 127.9 Gander Intl Air 126.9 127.1 Hopedale Intl Air 120.55 (shared with Gander ACC FL290 & above) Iqaluit Intl Air 126.9 Prins Christian Sund, Greenland Intl Air 127.9 134.95 Saglek 123.75 (shared with Gander ACC FL290 & above) Simiutaq 134.47 St. Anthony Intl Air 119.85 (shared with Gander ACC FL290 & above) 122.375 St. John's Intl Air 122.375 135.35 (shared with Gander ACC FL280 & below) Gander Radio Intl Air HF *Nat 'A' 3016 5598 8906 13306 (SELCAL) Nat 'B' 2899 5616 8864 13291 (SELCAL) Nat 'C' 2872 5649 8879 11336 13306 (SELCAL) Nat 'D' 2971 4675 8891 11279 (SELCAL) Nat 'F' 3476 6622 8831 13291 (SELCAL) VOLMET 3485 6604 10051 13270 *Note: The NAT Family A of frequencies is not routinely monitored by Gander IFSS; however, they are available for use in unusual circumstances such as an adjacent ATS Unit evacuation or loss communications. GANDER RADIO: INTERNATIONAL (NAT AND ANCHORAGE FIR) / DOMESTIC (CANADIAN NORTHERN AIRSPACE) For hours of operation and a description of HF Radiotelephony Network Operations for the North Atlantic refer to the AIP GEN section 3.4 Communication Services and for Anchorage Arctic Flight FIR refer to TC AIM NAT Section 2. SATCOM voice may be used to contact Gander Radio for non-routine flight safety calls or during periods of poor HF propagation. Gander Radio is responsible for (ICAO) HF communication in Canadian Northern Airspace and the Anchorage FIR. Aircraft operating within these areas may use SATCOM voice as an alternative to HF for routine communications. During periods of HF unreliability, the use of SATCOM voice for all communications is strongly encouraged. INMARSAT Short Code 431613, SATCOM Long Code 1-709-651-5328. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLVTPC GANDER - TRAINING AREAS GANDER VFR TERMINAL PROCEDURES CHART - TRAINING AREAS AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLVTPC-GOOSE BAY GOOSE BAY VFR TERMINAL PROCEDURES CHART AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYYR GOOSE BAY NL CYYR REF N53 19 09 W60 25 33 4.5NNW 21°W (2018) UTC-4(3) Elev 160´ A5020 LO7 HI1 CAP OPR 5 Wing Ops Centre 709-896-6900 Ext 7331 CSN 319-555-7331 800-563-2390, e-mail 5wgwoc@forces.gc.ca, for civ ctc Goose Bay Airport Corp 709-896-5445, e-mail operations@goosebayairport.com 12-21Z‡ Mon-Fri O/T 709-896-5755 Fax 709-896-2434 Ldg fees thru PVT ADV PF A-1,6 C-2,3,4,5 CUST AOE/15 Gen Avn 12-04‡ 888-226-7277 FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. MIL Flt ops 709-896-6900 Ext 7331 CSN 319-555-7331 800-563-2390, e-mail 5wgwoc@forces.gc.ca WX METAR H24. TAF H24, issue times: 00, 06, 12 & 18Z. O/T JMC 1-800-WXMETEO 996-3836 or CSN 432-2613. (See COMM) AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE SERVICES FUEL OIL S ARFF SUP FL JASU MIL ADV PVT ADV MIL CON All acft carrying dangerous goods, Class 1, division 1.1, 1.2, 1.3, 1.4 explosives 24 hr PPR thru 709-896-6900 Ext 7331 CSN 319-555-7331. Hg space avbl. Civ acft co-ordination thru FBO at PVT ADV. Mil acft co-ordination thru MIL ADV. 100LL, JA-1 (FSII avbl), F-34, SP, HPR All (128, 133, 156) 1,2 DESIGNATED CAT 8 LOX, LHOX, D & A-ice (24 hrs PN thru opr). CE13, 14, CA1 Flt Ops 129.85 350.5 709-896-6900 Ext 7331 CSN 319-555-7331. 800-563-2390, e-mail 5wgwoc@forces.gc.ca. Tran svcg thru Woodward Avn unicom 122.9 800-563-5202, 709-896-5036. Irving Avn 123.3 709-896-9090 Page 1-553-1092; Woodward Avn 122.9 709-896-5036, 800-563-5202 or 709-899-4660 Woodward Oil (Woodward’s Avn 709-896-5036) RWY DATA TWY RCR Rwy 08(076°)/26(256°) 11051X200 concrete with asphalt overlay Rwy 16(154°)/34(334°) 9580x200 concrete with asphalt overlay RAG: Rwy 08 BAK-12B(1300´); Rwy 26 BAK-12B(1350´); Nov 1-Mar 31 acft requiring cable 24 hr PN. Apr 1-Oct 31 1 hr PN thru opr. Twys G, J, K and H south of J uncontrolled. Twys A1 & K unlit. Uncontrolled vehicle rte on Twy G. Opr CRFI No win maint on Twy A1. PLR/PCN Rwy 08/26 PCN 86/F/B/W/T Rwy 16/34 PCN 59/R/B/W/T. LIGHTING 08-AN(non-std 3000´ (1600´ SF)) (TE HI) P2, 26-AN(TE HI) P2, 16-AS(TE HI) P2, 34-AD(TE HI) P2 COMM RCO ATIS CLNC DEL GND TWR TML PAL PMSV London rdo 123.475 (FISE) 126.7(bcst) 128.1 340.8 118.1 336.5 121.9 275.8 119.1 236.6 (E) 119.5 267.1 257T (E) 11-03Z‡ Mon-Sat O/T Gander Ctr Gander Ctr 120.4 294.5 344.6 NAV NDB VOR/DME TACAN ILS GOOSE YR 257 (M) N53 20 16 W60 21 57 GOOSE YYR 117.3 Ch 120 N53 19 11 W60 17 41 (92') GOOSE UYR 110.3 Ch 40 N53 19 11 W60 25 00 (200´) Preventive maint 12-16Z‡ Tue exc dur IFR. Unrel btwn 096°-036° beyond 30NM below 3500´; 356°-036° beyond 35NM below 4100´; 106°-136° beyond 35NM below 4100´; 136°-356° beyond 35NM below 5000´. IYR 110.3 (Rwy 08-26) RVR. Maint 12-16Z‡ Thu exc dur IFR. PRO Rgt hand circuits Rwy 26 (CAR 602.96). Tfc ptns: jets 1500 ASL, convl 1000 ASL. Mil jet tfc VFR recovery points; N – Hill (051° R/10NM); E – East of Lake (124° R/13NM); W – Falls (276° R/14NM); S – Lake (241° R/13NM). Acft should land beyond apch end arrestor cable when in up posn. Noise abatement Rwy 08 climb rwy hdg to 2000 ASL before turning. Noise abatement pro for sensitive area in vicinity of Northwest River/Sheshatshui N53 31.5 W60 09 (aprx YYR 046° R/14NM) & Mud Lake N53 18 W60 10 (aprx YYR 116° R/4.5 NM). All mil acft avoid flt below 2000 ASL within 2NM radius. Helo reporting pts - Helo will report over pts at 500 AGL: Helo 1 - CN Wharf; Helo 2 - Newfoundland Tel Twr; Helo 3 - Pumping Station; Helo 4 - Alexander Lake; Helo 5 - Abm Little Muskrat Lake. Unmarked fur farm loc N53 18.0 W60 22.0: Acft requested to avoid overflight of this farm below 1000 ASL within 0.5NM. All acft arriving or departing Goose (Otter Creek) ctc TWR prior to ldg or tkof. CAUTION Snow bank on apron btwn twy B & C Nov-May. Daily radiosonde balloon launches with an ascent rate of 1000 ft/min between the hrs of 1115-1345Z and 2315-0145Z Water Aerodrome, Goose (Otter Creek), 2.5 NM N. Small Arms Range lctd aprx. 1.5 NM NW of AD. Times of activation via ATIS or Goose Bay twr. GOOSE BAY NL (Cont’d) CYYR AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCFW8 GRAND FALLS-WINDSOR NL (Heli) CFW8 REF N48 55 29 W55 38 50 Adj 20°W (2014) UTC-3½(2½) Elev 157' A5011 A5012 OPR Town of Grand Falls-Windsor 709-489-0427/0430 Reg PF C-1,2,3,4,5,6 FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. SERVICES S 4 HELI DATA FATO 64' x 64' ASPH Safety Area 96’ x 89’ GRVL Parking Pad 1: 50’ dia ASPH Parking Pad 2: 50’ dia ASPH Parking Pad 3: 50’ dia ASPH RCR Opr Ltd win maint COMM ATF tfc 123.2 5NM 3200 ASL PRO Arr/dep btwn 108° & 318° fr heli. CAUTION Trees & brush in SE & SW arr/dep paths. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCHG2 HARBOUR GRACE NL CHG2 REF N47 41 08 W53 15 14 0.8W 19°W (2015) UTC-3½(2½) Elev 325´ A5012 OPR Town of Harbour Grace 709-596-3631/3042 Reg PF C-1,2,3,4,5 D-6 FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 09/27 2000x100 turf Rwy 27 down 4% RCR Opr No win maint COMM ATF tfc 123.2 5NM 3300 ASL CAUTION 65´ high rock outcrop 450´ E of Thld Rwy 27. Rwy may be soft when wet. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYHO HOPEDALE NL CYHO REF N55 26 56 W60 13 41 1W 23°W (2013) UTC-4(3) Elev 46´ A5020 LO7 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-2,3,4,5 FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 07(067°)/25(247°) 2501x75 gravel RWY CERT Rwy 07/25 AGN II RCR Opr 709-933-3851/3899 Ltd win maint LIGHTING 07-AS(TE ME) AP 4°, 25-AS(TE ME) AP 4° ARCAL-122.8 type K key mic 7 times for RILS. COMM RCO London rdo 123.65 (FISE) 126.7 (bcst) ATF tfc 122.8 5NM 3000 ASL See PRO section PAL Gander Ctr 135.4 INTL AIR Gander rdo 120.55 PRO Rgt hand circuits Rwy 07 (CAR 602.96). A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCLH7 LONG HARBOUR RIVER NL (Heli) CLH7 REF N47 54 16 W54 55 13 18°W (2018) UTC-3 1/2(2 1/2) Elev 300’ A5012 CAP OPR Canadian Northern Outfitters 709-738-5513 REG Jun-Sep PPR FLT PLN NOTAM FILE CYQX FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada and USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225 HELI DATA FATO/TLOF 20’ x 24’ WOOD Max heli overall length 20' RCR Opr COMM ATF tfc 123.2 5NM 3300 ASL AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCX2 LONG POND NL (Heli) CCX2 REF N47 30 58 W52 58 51 Adj 19°W (2013) UTC-31/2(21/2) Elev 42´ A5012 CAP OPR Cougar Helicopters Inc 709-758-4810 Reg PPR FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX 709-834-0016 METAR 08-22Z‡ (CWWU) TAF 08-22Z‡ (CWWU) HELI DATA FATO 92´ x 92´ ASPH/GRVL TLOF 39’ x 39’ ASPH/GRVL Safety Area 123’ x 123’ GRASS/GRVL RCR Opr LIGHTING RY(LO) ARCAL-122.8 type K COMM ATF tfc 123.2 5NM 3000 ASL NAV VOR/DME TORBAY YYT 113.5 Ch 82 N47 29 07 W52 51 08 (839´) PRO Arr/dep 285° to 050° fr heli, slope 8% (H3) day/night use. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYFT MAKKOVIK NL CYFT REF N55 04 38 W59 11 16 0.5W 22°W (2016) UTC-4(3) Elev 231´ A5020 LO7 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-1,2,4,5 FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX METAR 10-21Z‡ O/T LWIS RWY DATA Rwy 09(089°)/27(269°) 2592x75 gravel Rwy 09 down 1.35% RWY CERT Rwy 09/27 AGN II APRON Acft prkg not permitted S portion apron within 150´ fr rwy edge lights. RCR Opr 709-923-2328/2367 Ltd win maint, ctc opr LIGHTING 09-AS(TE ME) AP 4°, 27-AS(TE ME) AP 4° ARCAL-122.8 type K, key mic 7 times for RIL. COMM ATF tfc 122.8 5NM 3200 ASL See PRO section PRO A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. CAUTION Soft when wet. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYMH MARY'S HARBOUR NL CYMH REF N52 18 10 W55 50 52 0.5S 21°W (2014) UTC-3 1/2(2 1/2) Elev 35´ A5020 LO7 HI1 HI6 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-1,2,4,5 FLT PLN NOTAM FILE CYAY FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX METAR AUTO H24 (see COMM) WxCam TAF 10-04Z‡, issue times: 11, 14, 20, 02Z SERVICES FUEL JA-1 ctc 709-921-6220 RWY DATA Rwy 11(109°)/29(289°) 2545x75 GRVL Rwy 11 down 0.42% RWY CERT Rwy 11/29 AGN II RCR Opr 709-921-6961/6929 Ltd win maint LIGHTING 11-AS(TE ME) AV 4°, 29-AS(TE ME) AV 4° ARCAL-122.8 type K, key mic 7 times for RIL. COMM ATF tfc 122.8 5NM 3000 ASL See PRO section AWOS 122.55 NAV NDB YMH 250 (M) N52 18 52 W55 49 53 PRO Rgt hand circuits Rwy 11 (CAR 602.96). A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYDP NAIN NL CYDP REF N56 33 02 W61 40 56 24°W (2013) UTC-4(3) Elev 21´ A5027 LO5 HI1 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert (Day Ops only) PF C-1,2,4,5 FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX METAR 09-24Z‡ O/T LWIS TAF 11-24Z‡, issue times: 11, 14, 20Z (DT 10, 14, 20Z) RWY DATA Rwy 04(043°)/22(223°) 1986x75 gravel RWY CERT Rwy 04/22 AGN II APRON Acft prkg not permitted on that portion of the S apron within 30´ of apron edge. RCR Opr 709-922-2263/2169 Ltd win maint, ctc opr LIGHTING 04-AS, 22-AS ARCAL-122.8 type K COMM RCO ATF London rdo 123.65 (FISE) tfc 122.8 5NM 3000 ASL See PRO section NAV NDB YDP 247 (M) N56 32 02 W61 41 30 PRO A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. CAUTION Wind direction 270°-360° can cause turbulence & downdraft. Hills to 800 ASL 5000´ W of Thld 04. Terrain to 300' ASL 0.8NM SW and to 700' ASL 1.4NM SW Thld 04 within apch Rwy 04/tkof Rwy 22. Terrain marked with daytime markings. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCNH2 NATUASHISH NL CNH2 REF N55 54 50 W61 11 04 1.6W 23°W (2013) UTC-4(3) Elev 33´ A5020 LO7 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-1,2,4 FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX WxCam RWY DATA Rwy 12(118°)/30(298°) 2500x75 GRVL RWY CERT Rwy 12/30 AGN II RCR Opr 709-478-8745 Ltd win maint LIGHTING 12-AS(TE ME) P1, 30-AS(TE ME) P1 ARCAL-122.8 type K COMM ATF tfc 122.8 5NM 3000 ASL See PRO section NAV NDB E8 492 (M) N55 54 44 W61 11 22 Pvt PRO A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. CAUTION Power poles on approach Rwy 30. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCM4 PORT AU CHOIX NL CCM4 REF N50 41 20 W57 19 53 1.5SSE 21°W (2012) UTC-31/2(21/2) Elev 90´ A5011 OPR Govt of Newfoundland & Labrador 709-861-3505 or 709-729-3092 Reg PF C-1,2,5 D-3,4 FLT PLN FIC NOTAM FILE CYYT London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA RCR Rwy 08/26 2700x50 asphalt Opr Ltd win maint PN COMM ATF tfc 123.2 5NM 3100 ASL CAUTION Power line aprx 500' fr Thld 08. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCP4 PORT HOPE SIMPSON NL CCP4 REF N52 31 41 W56 17 07 1S 21°W (2013) UTC-3 1/2(2 1/2) Elev 339´ A5020 LO7 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-1,2,4,5 FLT PLN NOTAM FILE CYAY FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 12(119°)/30(299°) 2497x75 GRVL RWY CERT Rwy 12/30 AGN II RCR Opr 709-960-0383/0247 Ltd win maint, ctc opr LIGHTING 12-AS(TE ME) AV 4°, 30-AS(TE ME) AV 4° ARCAL-122.8 type K, key mic 7 times for RIL. COMM ATF tfc 122.8 5NM 3300 ASL See PRO section NAV NDB 6F 367 (L) N52 31 12 W56 17 45 Pvt Unmonitored PRO A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCD4 POSTVILLE NL CCD4 REF N54 54 37 W59 47 07 Adj 22°W (2016) UTC-4(3) Elev 223´ A5020 LO7 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-1,2,4,5 FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 06(055°)/24(235°) 2576x75 GRVL Rwy 06 down 1.40% RWY CERT Rwy 06/24 AGN II RCR Opr 709-479-9750/9819 Ltd win maint LIGHTING 06-AS(TE ME) AP 4°, 24-AS(TE ME) AP 4° ARCAL-122.8 type K, key mic 7 times for RIL. COMM ATF tfc 122.8 5NM 3200 ASL See PRO section NAV NDB 3R 366 (L) N54 54 27 W59 47 43 Pvt Unmonitored PRO Rgt hand circuits Rwy 24 (CAR 602.96). A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCZ2 RIGOLET NL CCZ2 REF N54 10 46 W58 27 26 Adj 22°W (2013) UTC-4(3) Elev 186´ A5020 LO7 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-1,2,4,5 FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX WxCam RWY DATA Rwy 11(110°)/29(290°) 2496x75 GRVL Rwy 29 up 0.6% RWY CERT Rwy 11/29 AGN II RCR Opr 709-947-3434/3384 Ltd win maint, ctc opr LIGHTING 11-AS(TE ME) AP, 29-AS(TE ME) AP ARCAL-122.8 type K, key mic 7 times for RIL. COMM ATF TML tfc 122.8 5NM 3200 ASL See PRO section Goose Bay 119.5 267.1 257T (E) 11-03Z‡ Mon-Sat O/T Gander Ctr PRO Rgt hand circuits Rwy 11 (CAR 602.96). A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. CAUTION 362´ twr 0.3NM ESE thld Rwy 29. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCD2 SPRINGDALE NL CCD2 REF N49 28 44 W56 10 41 4W 20°W (2015) UTC-31/2(21/2) Elev 250´ A5011 A5012 LO8 OPR Govt of Newfoundland & Labrador 709-292-4326 or 709-256-1048 Reg PF C-1,2,3,4,5 FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. SERVICES FUEL 100LL Ltd hrs Springdale Aviation 709-673-3313 OIL 80, 100 Ltd hrs Springdale Aviation 709-673-3313 RWY DATA RCR Rwy 10/28 2800x75 asphalt Opr Ltd win maint LIGHTING 10-(TE ME), 28-(TE ME) ARCAL-122.8 type J COMM ATF tfc 123.2 5NM 3300 ASL NAV NDB 2B 364 (L) N49 29 24 W56 11 05 Pvt Unmonitored PRO Rgt hand circuits Rwy 10 (CAR 602.96). CAUTION Possible wind shear on apch Rwy 28 due to deep ravine 100´ fr button. ARCAL lgt may not activate at lower alt due to higher terrain. Heli tfc W of A/D. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCDA5 ST. ANDREWS (CODROY VALLEY) NL CDA5 REF N47 46 32 W59 18 45 1.5NW 19°W (2013) UTC-31/2 (21/2) Elev 90´ A5011 A5012 LO8 CAP OPR Govt of Newfoundland & Labrador 709-955-2210 or 709-635-4100 Reg PF D-1,2,3,4,5 FLT PLN NOTAM FILE CYJT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 18(179°)/36(359°) 2995x75 ASPH Rwy 18 down 1.24% RCR Opr Ltd win maint PN LIGHTING 18-AS(TE ME), 36-AS(TE ME) ARCAL-122.8 type K, key mic 7 times for RIL COMM ATF tfc 123.2 5NM 3100 ASL ARR Gander Centre 120.325 DEP Gander Centre 120.325 CAUTION Anticipate downdrafts especially with strong SE winds. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYAY ST. ANTHONY NL CYAY REF N51 23 31 W56 04 59 19WNW 21°W (2013) UTC-31/2 (21/2) Elev 108´ A5011 LO7 LO8 HI1 HI6 CAP OPR TC 709-454-3192/3632. After hrs 709-450-0459, 709-454-4181 Cert Ldg fees (jet and turboprop acft only), Tml fees PF A-1,2,6 D-1,2,3,4,5,6 FLT PLN NOTAM FILE CYAY FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX METAR AUTO H24 (see COMM) TAF H24, issue times: 02, 08, 14, 20Z. WxCam SERVICES Call out chg may be levied for one or more svcs. FUEL JA-1 1130-2030Z‡ Mon-Fri O/T 1 hr PN Penney’s Acft Svcs 709-454-3839/3149/3191/3573 OIL All S 2, 5 RWY DATA Rwy 10(101°)/28(281°) 4003x100 asphalt Rwy 10 down 0.49% RWY CERT Rwy 10 RVR 1200(1/4sm)/Rwy 28 RVR 1200(1/4sm) AGN IIIA APRON Prkg fees RCR Opr CRFI 11-21Z‡ O/T 3 hrs PN (possible call out chg). PCN. LIGHTING 10-AO(TE ME) P1, 28-AO(TE ME) P1 ARCAL-122.3 type K COMM RCO Deer Lake rdo 122.3 (RAAS) London rdo 123.275 5680 (FISE) 126.7 (bcst) MF Deer Lake rdo 122.3 5NM 3100 ASL (CAR 602.98) PAL Gander Ctr 133.0 371.9 INTL AIR Gander rdo 119.85 122.375 AWOS 118.65 NAV NDB AY 356 (M) N51 23 12 W56 05 42 VOR/DME YAY 113.7 Ch 84 N51 23 38 W56 05 01 (133´) AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCK2 ST. JOHN’S (HEALTH SCIENCES CENTRE) NL (Heli) CCK2 REF N47 34 21 W52 44 44 1.5WNW 19°W (2012) UTC-3 1/2 (21/2) Elev 216’ A5012 OPR Eastern Health Care 709-777-5160 Cert PPR PF A-1 C- 5 FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) HELI DATA FATO/TLOF 123’ dia ASPH Safety Area 164’x164’ ASPH Max heli overall length 82' RCR Opr LIGHTING DR RY(LO) RF(FL) COMM TWR St. John's 120.6 (E) PRO Arr/dep 065° & 187° fr heli, slope 9.1% (H1). CAUTION Lgtd P-line aprx 262 ASL aprx 1540' E of heli safety area. P-Line oriented NW-SE Downslope, perpendicular to and within arr/dep path 065°. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLVTPC-ST JOHNS ST. JOHN’S INTL VFR TERMINAL PROCEDURES CHART AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCDC2 ST. JOHN'S (UNIVERSAL) NL (Heli) CDC2 REF N47 36 30 W52 43 37 19°W (2014) UTC-3 1/2(21/2) Elev 412´ A5012 OPR Universal Helicopters Nfld Ltd 709-576-4611 Cert PF B-1 C-2,3,4,5,6 FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. SERVICES S 2 HELI DATA FATO/TLOF 64’ x 64’ ASPH Safety Area 85’ x 85’ GRVL Max heli overall length 42.7’ RCR Opr Ltd win maint COMM TWR St. John's 120.6 (E) PRO Arr/dep 150° to 216° fr heli, slope 6% (H3) AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYYT ST. JOHN'S INTL NL CYYT REF N47 37 07 W52 45 09 3NW 19°W (2012) UTC-31/2(21/2) Elev 461´ A5012 LO8 HI6 CAP OC OPR St. John’s International Airport Authority Inc 709-757-4444 Cert PF A-1,2,3,6 C-4,5 CUST AOE/165 (450 with staged off-loading) 1130-0330Z‡ General aviation 888-226-7277 FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX METAR H24 TAF H24, issue times: 00, 06, 12, 18Z SERVICES FUEL 100LL, JA-1 (FSII avbl) O/R OIL All S 1,2,4 ARFF DESIGNATED CAT 7 (CAT 8 3 hr PN) SUP FL LPOX, D & A-ice JASU CAN-A Elect Start 10/15 MIL ADV Transient svcs avbl to RCAF and NATO acft thru Air Reserve Torbay Ops 709-570-4791 or 709-685-0243. Trans svcg avbl 1030-0230Z‡, aft hrs with 4 hr PN. Tow bars avbl for C130, P3, EH101, S61, C144 PVT ADV Woodward Aviation 123.5 709-579-3776 Fax 709-579-8513; Shell Aerocentre 123.0 709-576-4615 Fax 709-576-0768; Irving Aviation Svcs 122.9 709-758-3200 Fax 709-758-3201 MIL CON Woodward's Oil Ltd 709-579-3776 AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE RWY DATA Rwy 11(105°)/29(285°) 8502x200 asphalt Rwy 16(158°)/34(338°) 7005x200 asphalt Rwy 16 down 0.32% Rwy 02(015°)/20(195°) 5028x100 asphalt RESA: 16/34 492’; 11/29 492’ RWY CERT Rwy 11 RVR 600/Rwy 29 RVR 600 AGN V Rwy 16 RVR 1200(1/4sm)/Rwy 34 RVR 1200(1/4sm) AGN V Rwy 02 RVR 1200(1/4sm) Day/Rwy 20 RVR 1200(1/4sm) Day AGN IIIA TWY Twy K uncontrolled bcst intentions on 121.9 APRON All Aprons uncontrolled. Taxiing acft to remain on taxilanes. Acft shall not taxi btwn tml and pushed back acft. Acft with a wingspan of 52m (170.6ft) or more but less than 65m (213.3') shall access Apron I via Twy G only, rstd to Gate 1. Apron II rstd to acft with wingspan 52m (170.6’) or less. All turbine acft engine runs above idle power prohibited on Apron II. Apron II Helicopter FATO operations prohibited. RCR Opr CRFI Win field cond reports 709-757-4444. PLR/PCN LIGHTING 02-(TE HI) P2, 20-(TE HI) P2, 11-AL(TE HI CL TDZL) P3, 29-AL(TE HI CL TDZL) P3, 16-AN(TE HI CL) P3, 34-AS(TE HI CL) P3 COMM RCO London rdo 123.275 (FISE) 126.7 (bcst) ATIS 128.0 GND 121.9 275.8 TWR 120.6 236.6 (E) (emerg only 709-724-1055) PAL Gander Ctr 133.15 135.35 227.3 MIL Air Reserve Torbay Ops 131.02 INTL AIR Gander rdo 122.375 135.35 NAV NDB WABANA ZNF 270 (L) N47 37 09 W52 52 00 SIGNAL HILL NL 358 (L) N47 34 26 W52 41 08 VOR/DME TORBAY YYT 113.5 Ch 82 N47 29 07 W52 51 08 (839’) DME ISO 110.3 Ch 40 N47 37 26 W52 44 27 (474’) ILS IYT 110.7 (Rwy 16) RVR LOC reliable only within 10° either side of centreline; ISO 110.3 (Rwy 29) RVR LOC reliable only within 10° either side of centreline; IMP 109.1 (Rwy 11) RVR LOC reliable only within 10° either side of centreline ST. JOHN'S INTL NL (Cont’d) CYYT AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE PRO Pilots should refer to Canadian Airport Charts (CAC) to obtain details on established hot spots, prior to operating on maneuvering areas. CAC are available for free on the NAV CANADA website. DE-ICING OPERATIONS DE-ICING BAYS 1. Bay 1 - Max wingspan for de-icing ops 35.8m (117') 2. Bay 2 - Max wingspan for de-icing ops 35.8m (117'). Note: Bay 3 is closed/unusable when Bay 2 is occupied. 3. Bay 3 - Max wingspan for de-icing ops 79.75 (262'). Note: Bays 2 and 4 are closed/unusable when Bay 3 is occupied. 4. Bay 4 - Max wingspan for de-icing ops is 35.8m (117'). Note: Bay 3 is closed/unusable when Bay 4 is occupied. NOTE: The above noted max wingspans are intended to protect adj de-icing bays, safety zones and the apron twy. Exceedances of these values are permitted but must be evaluated and approved by the Aprt Authority to ensure special op procedures are communicated and implemented. DE-ICING PROCEDURES 1. Ctc ICEMAN on 129.2 30 min prior to pushback. 2. Ctc ST JOHN'S GND after pushback for taxi to CDF. 3. Hold short of CDF on H. 4. ST JOHN'S GND will advs flt crew to ctc ICEMAN on 129.2 when acft has taxied to the proper entry point. 5. ICEMAN will then delegate all further manoeuvering instructions from the entry point to and on the CDF. 6. Flt crews are advs to exercise discretion at all times while on the CDF. Directional signage and taxi lines on the CDF must be followed by flt crews at all times. 7. Upon completion flt crews must advs ICEMAN that all equipment and de-icing personnel are away from the aircraft and have returned to their designated safety zones. 8. ICEMAN will instruct the acft to hold its position on the CDF and ctc ST JOHN'S GND on 121.9. 9. Acft to hold its position until ST JOHN'S GND issues further taxi instructions from the CDF. NOTE: 1. Acft intending on returning to any apron after de-icing must drip dry for 25min on CDF. 2. Single engine taxi not permitted from CDF. 3. Engine run-ups are not permitted on CDF. CAUTION Open pit blasting ops 11NM SW to 1000 ASL 200 AGL, 1NM radius of N47 29 08 W52 57 11. Weather condition: No landing auth without electronic GP or vertical guidance capability when moderate to severe turbulence/wind shear/downdrafts being reported. Daily radiosonde balloon launches with an ascent rate of 1000 ft/min btwn hrs of 1115-1345Z and 2315-0145Z. Extv bird activity May-Nov. ST. JOHN'S INTL NL (Cont’d) CYYT AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCK4 ST. LEWIS (FOX HARBOUR) NL CCK4 REF N52 22 22 W55 40 26 Adj 21°W (2013) UTC-3 1/2(2 1/2) Elev 74´ A5020 LO7 CAP OPR Govt of Newfoundland & Labrador 709-896-7840 Cert PF C-1,2,4,5 FLT PLN NOTAM FILE CYAY FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 05(054°)/23(234°) 2208x75 GRVL Rwy 23 down 0.75% RWY CERT Rwy 05/23 AGN II RCR Opr 709-939-2241/2383 Ltd win maint LIGHTING 05-AS(TE ME) AV 4°, 23-AS(TE ME) AV 4° ARCAL-122.8 type K, key mic 7 times for RIL. COMM ATF Fox Harbour tfc 122.8 5NM 3100 ASL See PRO section PRO A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYJT STEPHENVILLE NL CYJT REF N48 32 40 W58 33 00 1.5SE 20°W (2014) UTC-31/2(21/2) Elev 81´ A5011 A5012 LO8 HI6 CAP OPR Stephenville Airport Corporation 709-643-8440/8445/8446 or 709-649-7585 or 877-663-8440 Fax 709-643-1295 Cert PF A-1,2,3,5,6 C-4 CUST AOE/30 12-20Z‡ Mon-Fri, AOE/15 Gen Avn only H24 exc hols 888-226-7277 FLT PLN NOTAM FILE CYJT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX 709-643-6815/8445 METAR H24 TAF H24, issue times: 00, 06, 12, 18Z SERVICES FUEL OIL S ARFF SUP FL JASU PVT ADV Call out chg, dependent on supplier, may be levied for one or more svcs. JA-1 (FSII avbl) Turbo 2380, Aviation EE80 1,2,3,6 PARTICIPATING CAT 6 (CAT 7 30 min PN) D-Ice CE13, CA1 Stephenville Aviation Svcs 122.725 YJT Ramp Svcs 122.725 709-649-9290 RWY DATA Rwy 09(091°)/27(271°) 10,011x200 asphalt Rwy 27 down 0.69% RWY CERT Rwy 09 RVR 1200(1/4sm)/Rwy 27 RVR 1200(1/4sm) AGN V RCR Opr CRFI, PLR/PCN LIGHTING 09-AD(non-std 1000') (TE HI) P3, 27-AN(TE HI) P3 AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE COMM RCO MF PAL London rdo 123.475 (FISE) 126.7 (bcst) aprt rdo 122.1 5NM 3100 ASL (CAR 602.98) Gander Ctr 120.325 NAV NDB HARMON ZJT 340 (L) N48 34 53 W58 22 49 VOR/DME YJT 113.1 Ch 78 N48 34 57 W58 40 09 (1190´) ILS IJT 109.5 (Rwy 27) RVR PRO Rgt hand circuits for gliders conducting westerly departures from abandoned area N of Rwy 09/27 (CAR 602.96). CAUTION Daily radiosonde balloon launches with an ascent rate of 1000 ft/min btwn hrs of 1115-1345Z and 2315-0145Z. Glider activity Apr-Oct in abandoned area N of Rwy 09/27. Vehicle launching. STEPHENVILLE NL (Cont’d) CYJT AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCVB2 VOISEY'S BAY NL CVB2 REF N56 20 41 W62 05 17 Adj 24°W (2013) UTC-4(3) Elev 246´ A5027 LO5 HI1 RCAP OPR Vale Inco 709-922-4270 Reg PPR FLT PLN NOTAM FILE CYYR FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. RWY DATA Rwy 11(107°)/29(287°) 5002x100 GRVL Rwy 29 up 0.5% Thld 29 displ 1198’ RCR Opr LIGHTING 11-(TE HI), 29-AO(TE HI) P1 4.5° ARCAL-122.7 type J COMM ATF UNICOM ltd hrs O/T tfc 122.8 5NM 3300 ASL See PRO section PRO A/D lies within ATF corridor 122.8 sfc to 12,500 ASL, see Section C – Areas With Discrete Air-To-Air Frequencies. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCYWK WABUSH NL CYWK REF N52 55 22 W66 51 53 1NE 21°W (2012) UTC-4(3) Elev 1809´ A5019 LO5 LO7 HI1 CAP OPR TC 709-282-5412 Cert Ldg fees (jet and turboprop acft only), Tml fees PF A-1,3,6 C-2,4,5 FLT PLN NOTAM FILE CYWK FIC ACC (bil) Québec 866-GOMÉTÉO or 866-WXBRIEF (Toll free within Canada) or 866-541-4105 (Toll free within Canada & USA). Flt Plns by Fax 418-871-4906 & include phone numbers where pilot can be reached prior to dep. (IFR only) Montreal 514-633-3211 or 800-633-1353 WX METAR 1100-0330Z‡ O/T METAR AUTO (see COMM) TAF H24, issue times: 02, 08, 14, 20Z WxCam SERVICES Call out chg may be levied for one or more svcs. De-icing PN 709-282-3333 FUEL JA-1 (FSII avbl) Avtech 709-282-8388 or 709-280-7127 or 709-280-0250 S 4,5,6 JASU 10/15 PN 709-282-3333 RWY DATA Rwy 18(181°)/36(001°) 6002x150 ASPH RWY CERT Rwy 18 RVR 1200(1/4sm)/Rwy 36 RVR 1200(1/4sm) AGN IIIB APRON Prkg stand are reserved for sked acft. Prkg fees. RCR Opr CRFI Win maint Oct-Apr 1100-2330Z‡ Sun-Fri, 1200-2030Z‡ Sat, avbl 3 hrs PPR 2330-0300‡ Sun-Fri. O/T MEDEVAC only 2 hr PN. PLR/PCN. LIGHTING 18-AO(TE HI) P2, 36-AN(TE HI) ARCAL-122.0 type K 0300-1100Z‡ COMM RADIO 122.0 296.2 (E) 1100-0330Z‡ (emerg only 709-282-6224) RCO Québec rdo 123.375 (FISE) 126.7 (bcst) ATIS 128.125 1100-0330Z‡ CLNC DEL 122.6 ltd hrs MF rdo 122.0 1100-0330Z‡ O/T tfc 5NM 4800 ASL (CAR 602.98) PAL Montréal Ctr 132.25 VDF 122.0 1100-0330Z‡ AWOS 128.125 0330-1100Z‡ NAV VOR/DME YWK 112.3 Ch 70 N52 57 36 W66 51 13 (2278´) DME IWK 110.1 Ch 38 N52 55 07 W66 51 37 (1815’) ILS IWK 110.1 (Rwy 36) CAUTION BLASTING: Mine blasting ops within 1.8NM radius N53 03 01 W066 57 31 (aprx 8.3NM N of A/D) to 5000 ASL, within 1.2NM radius N53 01 30 W066 49 16 (aprx 6.4NM NE of A/D) to 5000 ASL, within 1.6NM radius N52 54 29 W066 56 19 (aprx 2.8 NM W of A/D) to 2703 ASL, within 2.3NM radius N52 59 46 W066 56 44 (aprx 5.3NM NNW of A/D) to 5000 ASL, within 0.8NM radius N52 49 57 W67 17 19 (aprx 16NM W of A/D) to 5988 ASL and within 3.2NM radius N52 45 35 W67 18 46 (aprx 19NM WSW of A/D-Mont Wright Area) to 8000 ASL. WINDS: Winds reports E to SE unrel due terrain. APCH LIGHTING: Roadway lights similar to apch lighting 3NM from Thld 18, left of centreline. AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE NLCCC2 WINTERLAND NL CCC2 REF N47 08 13 W55 19 45 2.5SW 19°W (2013) UTC-31/2 (21/2) Elev 156´ A5012 LO8 CAP OPR Govt of Newfoundland & Labrador 709-891-1050 or 709-256-1048 Reg PF D-1,2,3,4,5,6 CUST AOE/15 888-226-7277 1215-2030Z‡ Apr 1-Sep 30; 1215-2030Z‡ Oct 1- Mar 31 Mon-Fri, exc hols FLT PLN NOTAM FILE CYYT FIC London 866-WXBRIEF (Toll free within Canada) or 866-541-4104 (Toll free within Canada & USA) ACC (IFR only) Gander 709-651-5225 or 888-751-5225. WX WxCam RWY DATA Rwy 15(147°)/33(327°) 2998x75 asphalt RCR Dept of Highways 709-891-1050 Ltd win maint PN LIGHTING 15-AS(TE ME), 33-AS(TE ME) ARCAL-122.8 type J COMM ATF tfc 123.2 5NM 3100 ASL NAV NDB MARYSTOWN 7H 234 (L) N47 08 14 W55 19 30 Pvt Unmonitored AERODROME / FACILITY DIRECTORY NEWFOUNDLAND AND LABRADOR CANADA FLIGHT SUPPLEMENT / GPH 205 Effective 0901Z 31 December 2020 to 0901Z 25 February 2021 SAMPLE CANADA FLIGHT SUPPLEMENT CAUTION: THE INFORMATION IN THIS PUBLICATION MAY BE SUPERSEDED BY NOTAM OR AIP SUPPLEMENT AIP Canada (ICAO) Part 3 - Aerodromes (AD) Department of National Defence Flip GPH 205 ATLANTIC TERMINAL AND ENROUTE DATA CFS DIGITAL EDITION DIGITAL EDITION EFFECTIVE 0901Z 31 December 2020 TO 0901Z 25 February 2021 SAMPLE CANADA FLIGHT SUPPLEMENT CAUTION: THE INFORMATION IN THIS PUBLICATION MAY BE SUPERSEDED BY NOTAM OR AIP SUPPLEMENT AIP Canada (ICAO) Part 3 - Aerodromes (AD) Department of National Defence Flip GPH 205 NOVA SCOTIA TERMINAL AND ENROUTE DATA CFS DIGITAL EDITION DIGITAL EDITION EFFECTIVE 0901Z 31 December 2020 TO 0901Z 25 February 2021 SAMPLE Published by NAV CANADA in accordance with ICAO Annexes 4 and 15 of the Convention on International Civil Aviation Cartography and Printing: NAV CANADA Source of Canadian Civil Aeronautical Data: © 2020 NAV CANADA All rights reserved Source of Canadian Military Aeronautical Data: Her Majesty the Queen in Right of Canada De
