Specification and Description Exhibit "A"

19.6 Garmin Avionics Installed in Single Engine Aircraft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 FIGURE I — STATIONAIR EXTERIOR DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 FIGURE II — STATIONAIR INTERIOR DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 FIGURE III — STATIONAIR INSTRUMENT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 March 2011 3 1 . G E N E R A L D E S C R I P T I O N All information herein applies to the Stationair (Model 206H). The Stationair is an all-metal, six-place, high- wing, fixed gear, single-engine piston aircraft designed for general utility purposes. 1.1 Certification The Model 206H is certified to the requirements of U.S. FAA Federal Aviation Regulation Part 23 through amendment 23-6, including day, night, VFR and IFR. 1.2 Approximate Dimensions Overall Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 ft 3.5 in (2.83m) Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 ft 3 in (8.61m) Wing Span (overall) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 ft (10.97m) Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174 sq ft (16.2sq m) Cabin Height (max) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49.5 in (1.26m) Width (trim to trim) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 in (1.12m) Length (firewall to aft baggage bulkhead) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145 in (3.68m) Cabin Door Height (front) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41 in (1.04m) Height (rear) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 in (1.00m) Width (top) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32.5 in (.83m) Width (bottom) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 in (.94m) Cargo Doors Height (front) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39.25 in (1.00m) Height (rear) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37.5 in (.95m) Width (top) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43 in (.1.09m) Width (bottom) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 in (.1.02m) 4 March 2011 FIGURE I — STATIONAIR EXTERIOR DIMENSIONS 9’ -3.5” 36’ -0” 28’ -3” 1 . G E N E R A L D E S C R I P T I O N ( C o n t i n u e d ) 13’ -0” 8’ -1” Max March 2011 5 FIGURE II — STATIONAIR INTERIOR DIMENSIONS 1 . G E N E R A L D E S C R I P T I O N ( C o n t i n u e d ) 35.00 65.00 36.00 42.00 44.00 *35.50 **42.50 *28.50 **34.50 *29.00 **30.00 Tiedown Rings (10 Standard) Firewall Firewall Face of Instrument Panel Code * Cabin Floor ** Lower Window Line Baggage Shelf 49.50 21.00 47.00 24.00 Rear Wall of Cabin 24.00 Forward Doorpost Bulkhead Cabin Height Dimensions Cabin Width Dimensions Cabin Floorplan Layout 45.50 *28.50 **36.00 *36.00 **40.00 *37.50 **42.00 *40.00 **43.50 *38.50 **44.00 *34.00 **42.00 *14.00 *14.00 6 1 . G E N E R A L D E S C R I P T I O N ( C o n t i n u e d ) 1.3 Design Weight and Capacities Maximum Ramp Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3,614 lbs (1,639 kg) Maximum Takeoff Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3,600 lbs (1,633 kg) Maximum Landing Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3,600 lbs (1,633 kg) Standard Empty Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2,254 lbs (1022 kg) Maximum Useful Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1,373 lbs (623 kg) Baggage Allowance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180 lbs (82 kg) Fuel Capacity Total Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92 gal (348.2 L) Total Useable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87 gal (329.3 L) Total Capacity each Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 gal (174.1 L) Total Useable Capacity each Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43.5 gal (164.6 L) Oil Capacity Sump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 qts (7.5 L) Total Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 qts (8.5 L) March 2011 March 2011 7 2 . P E R F O R M A N C E Service Ceiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15,700 ft Takeoff Distance S.L. (Ground Roll) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .910 ft Takeoff Distance S.L. (To Clear 50ft. Obstacle) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1860 ft Max Climb Rate S.L. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .988 fpm Max Speed (S.L.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151 kts / 174 mph Max Range and Endurance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .721 nm / 6.7 hrs Cruise Speed (75% pwr at 6,200 ft) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142 kts / 163 mph Cruise Range and Endurance (75% pwr at 6,200 ft) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .594 nm / 4.2 hrs Landing Distance (Ground Roll) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .735 ft Landing Distance (To Clear 50 ft Obstacle) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1395 ft All estimated performance data are based on airplane weights at 3,600 pounds; standard atmospheric condi- tions; level, hard surface, dry runways; and no wind. They are calculated values derived from flight tests con- ducted by Cessna Aircraft Company under carefully doc- umented conditions and will vary with individual air- planes, pilots, and numerous other factors affecting flight performance. 3 . P O W E R P L A N T & A C C E S S O R I E S z Lycoming IO-540-AC1A5 Engine z 300 HP @2700 RPM z Certified for 100LL & 100 Fuel z Fuel Injection System z Tubular Steel Engine Mount z Bed Dynafocal Engine Mounting System z Engine Driven Vacuum Pump z Automatic Alternate Engine Air z Oil Cooler z Rigid - Mounted Cowling z Manual Cowl Flaps z Induction Air Filter z Full Flow Oil Filter z Throttle Control z Vernier Mixture Control z Vernier Propeller Control z Dual Ignition System, Shielded Magneto z Engine Exhaust Muffler z McCauley Constant Speed, 3 Blade Metal Propeller z Propeller Governor z Propeller Spinner, Polished z Electric Starter 8 March 2011 z GMA-1347 Digital Audio Panel with Marker Beacon/Intercom z GTX-33 Transponder-Mode S w-TIS z GIA-63W NAV/COM/GPS/WAAS with GS #1 z GIA-63W NAV/COM/GPS/WAAS with GS #2 z GDU-1044B Primary Flight Display (PFD) z GDU-1044B Multi-Function Display (MFD) z GEA-71 Engine/Airframe Computer z GRS-77 AHRS z GDC-74A Air Data Computer with OAT Probe z GMU-44 Magnetometer z Garmin SafeTaxi & FliteCharts z GFC-700 Autopilot • Go-Around Switch • Electric Trim • A/P Disconnect • Control Wheel Steering Button z GDL-69A Flight Information System (FIS) with XM Radio z WX-500 Stormscope z Electronic Checklists z ME406 Two Frequency Emergency Locator Transmitter z Emergency Locator Transmitter Remote Mounted Switch z Backup Attitude Gyro, Altimeter and Airspeed Indicator z Control Wheel Push-To-Talk Switch-Pilot/Copilot z Mic & Phone Jacks-Pilot/Copilot/Passengers z Auxiliary Stereo Input Jack z Antennas: • Marker Beacon Antenna • Transponder Antenna • VHF/GPS Antenna (2) • XM Antenna • NAV Antenna • Emergency Locator Transmitter External Antenna • Stormscope Antenna z Pitot System - Heated z Static System z Hand Held Microphone z Alternate Static Source z Compass 4 . S T AT I O N A I R E Q U I P M E N T L I S T The following list of equipment is included on the stan- dard aircraft and it does not reflect optional equipment. NAV III Avionics Package 9 March 2011 5 . I N S T R U M E N T PA N E L 1. MASTER Switch (ALT and BAT) 2. STBY BATT Switch 3. STBY BATT Test Annunciator 4. AVIONICS Switch (BUS 1 and BUS 2) 5. Electrical Switches 6. GDU-1044B Primary Flight Display 7. Backup Attitude Gyro, Airspeed & Altimeter Indicator 8. GMA-1347 Audio Panel 9. Backup Compass 10. GDU-1044B Multi-Function Display 11. ELT Remote Switch/Annunciator 12. Flight Hour Recorder (Hobbs Meter) 13. Cabin Air Control 14. Wing Flap Switch Lever And Position Indicator 15. Mixture Control 16. Propeller Control Knob 17. Throttle (With Friction Lock) 18. Go-Around Switch 19. ALT Static Air Valve Control 20. Electrical and Avionics Circuit Breakers 21. Magnetos/Start Switch, Key Operated 22. Dimming Panel 21 22 1 2 3 4 5 6 8 10 11 12 13 14 15 16 17 18 19 20 7 FIGURE III — STATIONAIR INSTRUMENT PANEL 9 10 March 2011 6 . E L E C T R I C A L P O W E R z Alternator, 28 Volt, 95 Amp z Battery, 24 Volt, 10.0 AH (1 hr rate), Manifold Type z Standby Battery, 24 volt, 6.2 AH (1 hr rate), Sealed Type z Standby Battery Controller z Electrical Circuit Panel • Alternator/Battery Master Switch • Split Avionics Master Switch • Circuit Breakers, Electrical • Switches, Electrical z Electrical J-Box • Alternator Control Unit • Battery Current Sensor • Ground Service Receptacle • Starter Relay • Alternator Relay • Battery Relay • Ground Power Relay • Bus Circuit Protection z Cabin Power Jack -12 Volt (fore & aft) 7 . E N G I N E I N D I C AT I N G S Y S T E M ( E L E C T R O N I C ) z Ammeters z Voltmeters z Vacuum z Manifold Pressure z Oil Pressure and Temperature z Tachometer - Hour Recorder z Fuel Flow (GPH) z LH/RH Fuel Quantity z CHT - Cylinder Head Temperature z EGT - Exhaust Gas Temperature z Single Engine Driven Vacuum Pump System z Annunciation – Caution and Warning Alerts (PFD) 11 March 2011 9 . E X T E R I O R z Epoxy Corrosion Proofing, All Structure z LH Door, Pilot with Hinged Window, Lock and Key z RH Cargo Door, with Lock and Key z Openable Window – RH (Copilot) z Rear Window z All Windows Tinted z Fixed Landing Gear z White Polyurethane Exterior Paint z Refueling Steps and Handles, Wing Struts and Fuselage z Fixed Cabin Entrance Steps z Tie Down Rings, LH/RH Wing & Tail z Tube Type Tires • Nose – 5.00 X 5 • Mains - 6.00 X 6 z Conical Camber Wing Tip z Strut Braced, Camber Lift Wings z Static Wicks z Windshield Defroster, Pilot z Ventilator, Adjustable (6 places) z Heating System, Shrouded Muffler with Firewall Valve z Insulation / Soundproofing z Carbon Monoxide Detection System 8 . E N V I R O N M E N T A L z LED Ground Recognition Beacon - Vertical Tail z LED Navigation, LH/RH Wing Tip & Tail z Navigation Light Detectors, LH/RH z Wing Tip Strobe, LH/RH z Dual Wing LED Landing and Taxi Lights with integrated Pulse Recognition Technology z Underwing Courtesy, LH and RH 1 0 . E X T E R I O R L I G H T S z Hydraulic Brakes, Toe-Operated z Parking Brake z Stainless Steel Control Cables z Dual Flight Controls - Aileron/Elevator/Rudder z Leather Wrap Control Wheels, All Purpose Pilot/Copilot z Pilot Control Wheel Switches • Pitch Trim • AP Disconnect • Control Wheel Steering Button z Go-Around Switch z Elevator Trim - Manual/Electric z Rudder Trim - Manual z Electrical Preselect - Flaps z Steerable Nose Wheel z Aileron and Elevator Control Lock 1 1 . F L I G H T C O N T R O L S z Electric Auxiliary Fuel Pump z Engine Driven Fuel Pump z Integral Wet Wing Fuel Tanks, 87 Gal. Usable z Fuel Selector Valve, Left/Both/Right/Off z Fuel Strainer, Incorporated with Fuselage Quick Drain z Fuel Tank Quick Drain, 5 per wing z Fuel Sampler Cup z Fuel Vapor Return System 1 2 . F U E L S Y S T E M 12 March 2011 z LED Pilot/Copilot Cabin Overhead LED Lights z LED Passenger Overhead Lights z Interior Lights Dimming Controls z Map Light, Pilot Control Wheel z Sub-Panel Lighting (LED Backlighted) • Flaps • Throttle • Mixture • Propeller • Environmental Controls (Air and Heat) z Switch Panel Lighting (LED Backlighted) • Avionics and Master Switches • Dimming Rheostats • Landing, Taxi and Nav Switches • Beacon, Strobe, Fuel Pump, Pitot Heat • 12 Volt Cabin Power • Standby Battery Switch • Circuit Breakers • Ignition / Start Switch z LCD Lighted Glass Panel Displays: • Electronic Flight Instruments • Electronic Avionics Instruments • Electronic Engine Instruments z Audio Panel Bezel (Backlighted) z Radio Call Plate (Backlighted) z Compass Internally Lighted z Backup Attitude, Altimeter, Airspeed Internally Lighted 1 4 . I N T E R I O R L I G H T I N G z High Contrast Sport Interior Theme - Light Taupe and Black z Light Taupe Leather Seating Surface with Black Perforated (Embossed) Leather Inserts on Seat Cushion and Seat Back z Door Panel, Upper Sidewall Accent - Black Perforated (Embossed) Leather z Door, Lower Sidewall, Kick Panel - Black Kydex z Vinyl Grip Flooring in Crew Area z Carpeting in Passenger Area z Passenger Cup Holders z Jepp Map Storage Console with Cup Holders z Approach Plate Holder, Pilot Control Wheel z Armrests - Pilot & Copilot Doors/Passenger Side Panels z Amsafe Inflatable Seat Belts & Shoulder Harness STC, Inertia Reel, Pilot, Copilot, Passenger 3 & 4 Seats z Pilot and Copilot Seats • Adjustable Fore and Aft • Reclining Backs • Vertical Adjustment z Rear, Passenger 3 & 4 Seats (Removable) • Adjustable Fore and Aft • Reclining Backs z Rear, Passenger 5 & 6 Bench Seat (Removable) • Flat Folding z Pilot's Check List z Pilot's Operating Handbook z Fire Extinguisher, Hand Held z Instrument Panel Glareshield z Clothes Hanger Bar z Metal Instrument Panel, with Removable Stby Instr. Subpanel z Map/Glove Compartment z Baggage Net z Radio Call Plate z Map & Storage Pockets z Cabin Door Scuff Plates z Rosen Sun Visors, Pilot & Copilot z Tow Bar 1 3 . I N T E R I O R 13 March 2011 z Air Conditioning -Keith Products (STC -16,000 btuh / Engine Driven) z TAWS-B Terrain (Garmin) NAV III Avionics z ChartView powered by Jeppesen* z TAS Traffic (Bendix King KTA 870) – NAV III Avionics z ADF KR87 – NAV III Avionics – Separate control head - displayed on PFD (International only) z DME KN63 – NAV III Avionics – Integrated control - displayed on PFD (International only) z Floatplane Provision Kit (Exchange Items: Hoisting Rings, Windshield V-brace) z Oversized Tires and Wheel Fairings (Exchange: Main 8.00 x 6. Nose 6.00 x 5) z Cargo Pod (16.0 Cu. Ft. of Additional Cargo Space With Loading Up to 300 lbs) z Abrasion Boots (Horizontal Stabilizer) z C406N Three Frequency Emergency Locator Transmitter with GPS Interface z Synthetic Vision Technologies (SVT) - Garmin - Synthetic Vision utilizes GPS-based graphic technolo- gy providing virtual depiction of terrain and water fea- tures, complete with obstacles and, in the case of air- craft equipped with Traffic Alert and Collision Avoidance (TCAS) systems, airborne traffic, in 3-D perspective that allows pilots enhanced visual cues and improved situational awareness regardless of meteorological or lighting conditions *This option provides enablement only and does not include a Jeppesen subscription. Subscriptions are available from Jeppesen at www.jeppesen.com *Either Jeppesen ChartView or Garmin FliteCharts may be configured on your system, but not both. By selecting the ChartView option you are electing to disable Garmin FliteCharts. 1 5 . O P T I O N A L E Q U I P M E N T 1 6 . E X T E R I O R S T R I P I N G O P T I O N S z 523H: Matterhorn White and Carbon Black Metallic overall with Blue Effect painted stripes; Cessna logo: Gloss Black vinyl, Stationair logo and registration number: White vinyl z 523I: Matterhorn White and Blue Effect overall with Carbon Black Metallic painted stripes; Cessna logo: Gloss Black vinyl, Stationair logo and registration number: White vinyl z 523J: Matterhorn White and Platinum overall with Gloss Black painted stripes; Cessna logo, Stationair logo and registration number: Gloss Black vinyl z 523K: Matterhorn White and Gloss Black overall with Platinum painted stripes; Cessna logo: Gloss Black vinyl, Stationair logo and registration number: White vinyl z 523L: Matterhorn White and Maroon Shadow overall with Antique Silver painted stripes; Cessna logo: Dark Tundra Metallic vinyl, Stationair logo and registration number: White vinyl z 523M: Matterhorn White and Antique Silver overall with Maroon Shadow painted stripes; Cessna logo, Stationair logo and registration number: Dark Tundra Metallic vinyl z 523N: Matterhorn White and Antique Silver overall with Dark Red Effect painted stripes; Cessna logo, Stationair logo and registration number: Burgundy Metallic vinyl z 523O: Matterhorn White and Dark Red Effect overall with Antique Silver painted stripes; Cessna logo: Burgundy Metallic, Stationair logo and registration number: White vinyl z Fabric Seat Surfaces z Utility Interior Kit z Vinyl Grip Flooring z Kydex Door Sidepanel - Vinyl Inserts 1 7 . I N T E R I O R O P T I O N S z Cessna will offer one G1000 training course at no addi- tional charge and one G1000 ground school course for a second person at no additional charge, with pur- chase of a new aircraft. This offer is valid for 12 months after aircraft delivery. 1 8 . T R A I N I N G 14 March 2011 19.1 CESSNA'S LIMITED WARRANTY - SINGLE ENGINE PISTON AIRCRAFT Cessna warrants the aircraft and all parts included there- in to be free from defects in material and workmanship under normal use and service for a period of twenty-four (24) months after the Warranty Start Date, except as hereafter noted. Engines, engine part accessories, avionics, batteries, propellers and governors are specif- ically excluded from this warranty. Paint and graphics warranties are addressed separately. Spare parts sold by Cessna, excluding engines, engine part accessories, avionics, batteries, propellers and gov- ernors are warranted for six (6) months after installation, except as hereafter noted. Cessna's obligation under this warranty is limited to repairing or replacing, at its option, with exchange, over- hauled, or new parts, items found defective by Cessna’s examination which are returned at the owner’s expense within the applicable twenty-four (24) or six (6) month period to any Cessna Service Station. A new warranty period is not established for replace- ment parts. Replacement parts are warranted only for the remainder of the applicable twenty-four (24) or six (6) month original warranty period. The repair or replacement of defective parts under this warranty will be made without charge to the owner for parts and labor for removal, installation and/or actual repair, except that the owner shall pay all import duties and sales and use taxes on replacements and repairs. This limited warranty does not apply to parts subjected to misuse, negligence, improper installation, accident, alteration; repairs not authorized by Cessna; normal maintenance services (cleaning, control rigging, brake and other mechanical adjustments, maintenance inspections, etc.); replacement of service items (light bulbs, brake linings, filters, hoses, tires, cowl mounts, etc.); or to normal deterioration of soft trim or appear- ance items (paint, upholstery, rubber-like items, etc.) due to corrosion, wear and exposure. WITH THE EXCEPTION OF THE WARRANTY OF TITLE, TO THE EXTENT ALLOWED BY APPLICABLE LAW, THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY OTHER WARRANTIES, EXPRESSED OR IMPLIED IN FACT OR BY LAW, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. THE REMEDIES OF REPAIR OR REPLACEMENT AS ABOVE SET FORTH ARE THE ONLY REMEDIES UNDER THIS WARRANTY. CESSNA DISCLAIMS ANY OBLIGATION OR LIABILITY WHETHER IN CON- TRACT OR IN TORT (AND WHETHER FOR NEGLI- GENCE, STRICT LIABILITY, PRODUCT LIABILITY OR OTHERWISE), INCLUDING LOSS OF USE OF THE PRODUCT WARRANTED, LOSS OF TIME, INCONVENIENCE, COMMERCIAL LOSS OR ANY OTHER DIRECT, CONSEQUENTIAL, SPECIAL OR INCIDENTAL DAMAGES. THIS WARRANTY IS IN LIEU OF ANY OTHER OBLIGATION OR LIABILITY OF CESSNA OF ANY NATURE WHATSOEVER BY REA- SON OF THE MANUFACTURE, SALE OR LEASE OF SUCH AIRCRAFT PRODUCTS AND CESSNA NEI- THER ASSUMES NOR AUTHORIZES ANYONE TO ASSUME FOR IT ANY OTHER OBLIGATION OR LIA- BILITY IN CONNECTION WITH SUCH AIRCRAFT PRODUCTS. COMPLIANCE WITH THIS LIMITED WARRANTY MAY BE AFFECTED IF EXPORT LICENSES ARE REQUIRED TO BE REQUESTED AND APPROVED BEFORE SPARE PARTS CAN BE SHIPPED TO CERTAIN FOREIGN COUNTRIES. 19.2 AIRCRAFT PAINT AND GRAPHICS– SINGLE ENGINE PISTON AIRCRAFT Cessna endeavors to select and use high quality polyurethane paints from the leading manufacturers. Polyurethane paints and graphics are used because of their high gloss characteristics and ability to withstand dramatic temperature and pressure changes. The paint on your new aircraft will maintain its high gloss charac- teristics for an extended period of time provided it is cared for properly. The painted exterior surfaces require an initial curing period which may be as long as ninety (90) days after the finish is applied. During this curing period, some pre- cautions should be taken to avoid damaging the finish or interfering with the curing process. The finish should be cleaned only by washing with clean water and mild soap, followed by a water rinse and drying with a cloth or chamois. Do not use polish or wax, which would exclude air from the surface, during this ninety (90) day curing period. Once the finish has cured completely, it may be waxed with a good automotive wax, but power buffing should be avoided to prevent damage to the paint sur- face. Normal paint maintenance will include but is not limited to; touchup of abrasion and wear of the paint on screws heads, around access panels, the radome, wing leading edges, vertical and horizontal stabilizer leading edges, windshield retainers and other leading edge surfaces including parts on the landing gear subject to damage or erosion from airborne particles. Proper maintenance includes keeping surfaces clean, polished, and touching up chipped or eroded areas to prevent further damage and corrosion. Paint and graphics warranty applies only to defects in material and workmanship for a period of one (1) year from the Warranty Start Date. Deterioration of paint and graphics due to normal wear, exposure, or improper care is not covered by the warranty. If proper paint main- tenance procedures have been followed and paint peel- ing, blistering or cracking is evident in areas other than immediate leading edge surfaces, warranty considera- tion may be requested thorough a Cessna Service Station. 1 9 . L I M I T E D W A R R A N T Y 15 March 2011 Generally speaking, warranty repair of paint is confined to a limited surface area. Workmanship or material defects can usually be identified to localized surface areas that were improperly prepared prior to paint appli- cation, or to areas where the paint or subsurface primer has been improperly applied. Complete strip and repaint of an entire airplane can ONLY be authorized if there is evidence of paint defects on several major surface areas of the aircraft. Contact your Cessna Field Service Engineer concerning paint defects on any major surface of an aircraft. 19.3 Textron Lycoming Warranty (Limited) New Reciprocating Aircraft Engine What Textron Lycoming Promises You Engine Model Aircraft Model IO-360-L2A Cessna-172R, 172S IO-540-AB1A5 Cessna-182T IO-540-AC1A5 Cessna-206H TIO-540-AK1A Cessna-T182T TIO-540-AJ1A Cessna-T206H Textron Lycoming warrants the above listed new recip- rocating engine models sold by it to be free from defects in material and workmanship for a period of twenty-four (24) months after aircraft delivery to the original retail purchaser or first user. The date of first operation must not exceed two (2) years from the date of shipment from Textron Lycoming. Textron Lycoming's obligation under this warranty shall be limited to its choice of repair or replacement, on an exchange basis, of the engine or any part of the engine, when Textron Lycoming has determined that the engine is defective in material or workmanship. Such repair or replacement will be made by Textron Lycoming at no charge to you. Textron Lycoming will also bear the cost for labor in connection with the repair or replacement as provided in Textron Lycoming's then current Removal and Installation Labor Allowance Guidebook. Any engine or part so repaired or replaced will be enti- tled to warranty for the remainder of the original warran- ty period. YOUR OBLIGATIONS The engine must have received normal use and service. You must apply for warranty with an authorized Textron Lycoming distributor within 30 days of the appearance of the defect in material or workmanship. Textron Lycoming's warranty does not cover normal maintenance expenses or consumable items, the obli- gations on the part of Textron Lycoming set forth above are your exclusive remedy and the exclusive liability of Textron Lycoming. This warranty allocates the risk of product failure between you and Textron Lycoming, as permitted by applicable law. Textron Lycoming reserves the right to deny any warran- ty claim if it reasonably determines that the engine or part has been subject to accident or used, adjusted, altered, handled, maintained, or stored other than as directed in your operator's manual, or if non-genuine Textron Lycoming parts are installed in or on the engine and are determined to be a possible cause of the inci- dent for which the warranty application is filed. Textron Lycoming may change the construction of engines at any time without incurring any obligation to incorporate such alterations in engines or parts previ- ously sold. THIS LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES AND REPRE- SENTATIONS, EXPRESS OR IMPLIED OR STATUTO- RY, WHETHER WRITTEN OR ORAL, INCLUDING BUT NOT LIMITED TO ANY WARRANTY OF MER- CHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE, AND ANY IMPLIED WARRANTY ARISING FROM ANY COURSE OF PERFORMANCE OR DEAL- ING OR TRADE USAGE. THIS WARRANTY IS ALSO IN LIEU OF ANY OTHER OBLIGATION, LIABILITY, RIGHT, OR CLAIM, WHETHER IN CONTRACT OR IN TORT, INCLUDING ANY RIGHT IN STRICT LIABILITY IN TORT OR ANY RIGHT ARISING FROM NEGLI- GENCE ON THE PART OF TEXTRON LYCOMING, AND TEXTRON LYCOMING'S LIABILITY ON SUCH CLAIM SHALL IN NO CASE EXCEED THE PRICE ALLOCABLE TO THE ENGINE OR PART WHICH GIVES RISE TO THE CLAIM. LIMITATION OF LIABILITY IN NO EVENT, WHETHER AS A RESULT OF A BREACH OF WARRANTY, CON- TRACT, OR ALLEGED NEGLIGENCE, SHALL TEX- TRON LYCOMING BE LIABLE FOR SPECIAL OR CONSEQUENTIAL OR ANY OTHER DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF PROF- ITS OR REVENUES, LOSS OF USE OF THE ENGINE, OR COST OF A REPLACEMENT. No agreement varying this warranty or Textron Lycoming's obligations under it will be binding upon Textron Lycoming unless in writing signed by a duly authorized representative of Textron Lycoming. Cessna Model Aircraft Only Textron Lycoming Engines 652 Oliver Street Williamsport, Pennsylvania 17701 (570) 323-6181 www.lycoming.textron.com Original Engine Installation Only Effective 2000 1 9 . L I M I T E D W A R R A N T Y ( C o n t i n u e d ) 16 March 2011 19.4 McCauley Propeller Systems Standard Limited Warranty McCauley Propeller Systems, a Division of Cessna Aircraft Company, Wichita, Kansas, U.S.A., expressly warrants new and remanufactured products produced and sold by McCauley to be free from defects in materi- al and workmanship under normal use and service for a period of thirty-six (36) months after delivery to the orig- inal retail purchaser or until the expiration of the maxi- mum hours of use or calendar limits for overhaul pub- lished by McCauley for the subject product, whichever occurs first. McCauley’s obligation under this limited warranty is lim- ited to repairing or replacing, at its sole option, any pro- peller, propeller parts, governor or governor parts deter- mined by McCauley to have been defective and which are properly returned by the owner, with a written state- ment describing the alleged defect, to any McCauley Authorized Service Center authorized to service the indi- vidual McCauley product. The repair or replacement of defective parts will be made without charge to the owner for parts, or labor for removal and installation, except export/import duties, and/or sales or use taxes, if any which are solely the owner’s responsibility. McCauley will warrant a part replaced pursuant to this limited war- ranty under the same terms as the original part for the remainder of he applicable warranty period of the origi- nal part. This limited warranty is not intended to and does not cover the costs of normal maintenance of over- haul. In addition, McCauley will repair or replace, at its option, any propeller, propeller parts, governor, or governor parts requiring replacement due to manufacturing defect if found at or before the first recommended overhaul interval as described in McCauley published service information. This first overhaul coverage does not include labor, standard overhaul replacement parts, parts repairable via published service information (re- plating, painting, etc.), other costs associated with the propeller or governor overhaul, or export/import duties, and/or sales or use taxes, nor does it apply to defects found after McCauley published overhaul hour or calen- dar limits. The provisions of this limited warranty do not apply to: any McCauley parts which have been subject to misuse, negligence or accident or which have been repaired or altered in any way that, in the sole judgment of McCauley, adversely affects their performance, stabil- ity or reliability; to normal maintenance services (such as cleaning, mechanical adjustments and maintenance inspections); to the replacement of service items made in connection with normal maintenance; to normal dete- rioration of soft trim and appearance items (such as paint and rubber-like items) due to wear and exposure; to propellers, governors or parts found defective beyond the McCauley recommended overhaul period; or to parts which have been improperly installed by entities other than McCauley and/or McCauley Authorized Service Centers. The McCauley limited warranty is void on any new or remanufactured product installed, without McCauley’s prior written approval, on a non-type certificated engine, or on any engine which has received an overhaul or modification which is not approved by the engine manu- facturer and that results in a change to the vibratory environment of the engine such as, but not limited to, an alteration of horsepower, operating RPM, crankshaft damper configuration, compression ratio, magneto tim- ing, camshaft design, or any other overhaul or modifica- tion not expressly approved by the original engine man- ufacturer. The McCauley limited warranty is also void on any McCauley product shipped new from the factory or distributor in disassembled state, then later re-assem- bled by an unauthorized party. Parties authorized to re- assemble factory-new product must have specific writ- ten permission from McCauley to do so, otherwise all McCauley warranty on the affected unit is void. No McCauley warranty coverage is offered for leakage on product assembled outside McCauley, regardless of the assembling party. To the extent allowed by applicable law, THIS WAR- RANTY IS EXPRESSLY IN LIEU OF ANY OTHER WARRANTIES, EXPRESSED OR IMPLIED IN FACT OR BY LAW, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PAR- TICULAR PURPOSE. THE REMEDIES OF REPAIR OR REPLACEMENT SET FORTH HEREIN ARE THE ONLY REMEDIES UNDER THIS LIMITED WARRAN- TY. McCAULEY DISCLAIMS ANY OBLIGATION OR LIABILITY, WHETHER IN CONTRACT OR IN TORT , INCLUDING LOSS OF USE OF THE PRODUCT WAR- RANTED, LOSS OF TIME, INCONVENIENCE, LOSS OF PROFITS, COMMERCIAL LOSS, OR ANY OTHER DIRECT, CONSEQUENTIAL, SPECIAL, OR INCIDEN- TAL DAMAGES. THIS WARRANTY IS IN LIEU OF ANY OBLIGATION OR LIABILITY ON THE PART OF McCAULEY TO ANYONE OF ANY NATURE WHAT- SOEVER BY REASON OF THE MANUFACTURE, SALE, LEASE, OR USE OF THE WARRANTED PRODUCTS AND McCAULEY NEITHER ASSUMES NOR AUTHORIZES ANYONE TO ASSUME FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CON- NECTION WITH SUCH WARRANTED PRODUCTS. THE UNITED NATIONS CONVENTION ON CON- TRACTS FOR THE INTERNATIONAL SALE OF GOODS, 1980, AND ANY SUCCESSOR THERETO, IS EXPRESSLY EXCLUDED FROM THIS WARRANTY. Issued 9/1/2003 1 9 . L I M I T E D W A R R A N T Y ( C o n t i n u e d ) 17 March 2011 19.5 Bendix/King Equipment Retail Warranty Statement For Cessna Aircraft Company Single Engine Program A. General Aviation Avionics products manufactured by Honeywell under the brand name Bendix/King (collec- tively referred to herein as "Honeywell") are warranted against defects in design, material, or workmanship caused by Honeywell or its authorized agent(s) for the warranty period as defined in Paragraph (B) of this state- ment, which occur under normal and intended use and service, subject to all of the qualifications and conditions hereinafter stated. B. The warranty term for new product(s) installed on new aircraft shall be twenty-four (24) months from delivery to the original retail purchaser or first user. Cessna to pro- vide warranty start date information. C. Any product Honeywell finds to be in violation of the warranty as set out in Paragraph (A) hereof, at the option of Honeywell, shall be repaired, replaced, or exchanged in accordance with the following procedures: 1. Products shall be returned to any authorized Honeywell Service Center or Honeywell Regional Product Support Repair/Overhaul Facility, with trans port harges prepaid. 2. After correction, the products shall be returned to the purchaser with surface transportation charges prepaid. 3. The risk of loss or damage to all products in tran sit shall be borne by the party initiating the trans portation of such products unless the purchaser makes a request for specific mode of transportation. In such case, the risk of loss and the cost of ship ment shall be borne by the purchaser. All items repaired or replaced hereunder shall be warranted for the unexpired portion of the original warranty period. D. This warranty specifically excludes defects that Honeywell determines to be the result of any or all of the following: 1. Abuse, accident, or misuse; 2. Contamination, negligence, tampering, or improper storage or maintenance; 3. Repair or attempted repair by unauthorized per sons or use of non-Honeywell or unauthorized repair or replacement parts; 4. Products not installed by an authorized Honeywell Installation Facility in accordance with the appropri ate installation manual. E. The warranty as set out in Paragraph (A) is the only warranty for Honeywell products and is in lieu of all other warranties expressed or implied, including the implied warranties of merchantability and fitness for a particular purpose that are herewith expressly excluded and dis- claimed. F. The remedies as set out in Paragraph (C) hereof state the entire liability of Honeywell and constitute the sole and exclusive remedy of the purchaser. Honeywell shall not be liable for any other claim, loss, or damage, includ- ing, but not limited to, incidental, consequential, or other kinds of damages whether based on contract, tort, neg- ligence, or other theory of product liability. G. Honeywell reserves the right to make design changes, additions to, and improvements in its products without the obligation to install same in products previ- ously manufactured. THIS IS A LIMITED WARRANTY Honeywell 23500 W. 105th Street Olathe, Kansas 66061 19.6 Garmin Avionics Installed in Single Engine Aircraft Aircraft OEM-Installed Avionics 2-Year Limited Warranty Policy This GARMIN Product is warranted to be free from defects in materials or workmanship for two years from the date of warranty activation. Within this period, GARMIN International, Inc. will at its sole option, repair or replace any components which fail in normal use. Such repairs or replacement will be made at no charge to the customer for parts or labor, provided that the cus- tomer shall be responsible for any transportation cost. This warranty does not cover failures due to abuse, mis- use, accident or unauthorized alteration or repairs. THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED OR STATUTORY, INCLUDING ANY LIABILITY ARISING UNDER ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, STATUTORY OR OTHERWISE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY FROM STATE TO STATE. IN NO EVENT SHALL GARMIN BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSE- QUENTIAL DAMAGES, WHETHER RESULTING FROM THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT OR FROM DEFECTS IN THE PROD- UCT. Some states do not allow the exclusion of inciden- tal or consequential damages, so the above limitations may not apply to you. GARMIN retains the exclusive right to repair or replace 1 9 . L I M I T E D W A R R A N T Y ( C o n t i n u e d ) 18 March 2011 the product or offer a full refund of the purchase price at its sole discretion. SUCH REMEDY SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY. To obtain warranty service, contact your local GARMIN authorized Service Center. For assistance in locating a Service Center near you, call GARMIN Customer Service at one of the numbers shown below. GARMIN International 1200 East 151st Street Olathe, Kansas 66062, U.S.A. Toll free: 1-800-800-1020 Phone: 1-913-397-8200 FAX: 1-913-397-0836 GARMIN (Europe) Ltd. Unit 5, The Quadrangle Abbey Park Industrial Estate Romsey, SO51 9AQ, U.K. Phone: 44-1794-519944 FAX: 44-1794-519222 Visit our web site at: www.garmin.com 1 9 . L I M I T E D W A R R A N T Y ( C o n t i n u e d ) Cessna Single Engine Piston Aircraft, 2625 S. Hoover Rd. Wichita, Kansas 67215 Telefax: 316.517.2772
